Renault Ceres 85 X (A)

Built: 11/1994–9/1998 · Series: CERES-X Baureihe

More machines from model year 1994

Source: https://www.lectura-specs.com/en/model/agricultural-machiner

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the Ceres 85 X (A), Renault offers a model from the CERES-X series. Production: 11/1994–9/1998. The engine delivers 75 hp (55.2 kW), has 4 cylinders, with a displacement of 4,625 cm³. Torque is 261 Nm. Rated speed is 2,350 rpm. The machine is 4,087 mm long, 1,929 mm wide and 2,550 mm high. The unladen weight is 3,480 kg. The wheelbase measures 2,470 mm. Ground clearance is 490 mm. Top speed is 30 km/h. Transmission: 18 V/18 R or 20 V/20 R. The engine is water-cooled. Tyres: front 7.50-18 ASF (A: 13.6 R 24 AS), rear 16.9 R 34 AS. The fuel is diesel. The bore measures 106.5 mm. The stroke is 127 mm. The compression ratio is 17.2:1. Maximum torque is reached at 1,341 rpm. Construction: unit construction (no separate frame). Injection pressure is 245 bar. Around 49 (A: 596) units were built. Rated output across the Renault range ranges from 16 to 250 hp; the Ceres 85 X (A) sits in the lower part of that range with 75 hp. Its immediate neighbours are the 94 below it with 72 hp and the 80-14 F above it with 76 hp. Rated output across the Renault range ranges from 11.8 to 184 kW; here the Ceres 85 X (A) sits in the lower part of that range with 55.2 kW. 3632 Renault models across 98 series are on record.

Renault CERES-X series – four-cylinder tractors from Renault Agriculture: Ceres 85 X (A) and Ceres 95 X (A), 55.2 to 62.6 kW, 3,920 to 4,625 cm³, 261 to 289 Nm

The CERES-X range from Renault Agriculture of Le Mans also carries the name of the Roman goddess of agriculture, Ceres. It comprises the Ceres 85 X (A) and Ceres 95 X (A) models, whose A suffix marks an equipment variant. The X suffix in the model designation marked, for Renault, a particular equipment and technology level within this range.

Read on 3 more paragraphs

The register lists here 2 versions with 55.2 to 62.6 kW from four-cylinder engines of 3,920 to 4,625 cm³, an unladen weight of 3,455 to 3,480 kg, a length of 4,087 mm, a width of 1,929 mm, a height of 2,550 mm, torque of 261 to 289 Nm and a rated speed of 2,350 rpm.

The Ceres-X range covered the mid power band of the Renault line-up and targeted medium-sized arable and grassland farms in France and the rest of Western Europe. It thus occupied a market segment between the more compact standard tractors and the large Renault ranges of the time.

Buyers of used units should check the injection system, clutch and gearbox, as well as the hydraulics, cab seals and rust on the frame; spares run through the Claas dealer network, which took over support for the older Renault ranges. Before purchase it is also worth checking the front axle, steering and the condition of the hydraulic lines. A look at the service history helps assess how the tractor has been used.

Sources: SpecCodex register, model data: Renault CERES-X Baureihe

Technical data

Engine

Fuel	dieselcorrect
Power	75 hp (55.2 kW)correct
Rated speed	2,350 rpmcorrect
Torque	261 Nmcorrect
Speed at max. torque	1,341 rpmcorrect
Cylinders	4correct
Displacement	4,625 cm³correct
Bore	106.5 mmcorrect
Stroke	127 mmcorrect
Compression ratio	17.2correct
Injection pressure	245 barcorrect
Cooling	water-cooledcorrect

Dimensions and weights

Length	4,087 mmcorrect
Width	1,929 mmcorrect
Height	2,550 mmcorrect
Wheelbase	2,470 mmcorrect
Ground clearance	490 mmcorrect
Unladen weight	3,480 kgcorrect

Drivetrain and chassis

Drive	rear- or four-wheel drivecorrect
Gearbox	18 V/18 R or 20 V/20 Rcorrect
Front tyres	7.50-18 ASF (A: 13.6 R 24 AS)correct
Rear tyres	16.9 R 34 AScorrect
Top speed	30 km/hcorrect

Origin and approval

Construction	unit construction (no separate frame)correct
Units built	49 (A: 596)correct

Where this model stands

Power-to-weight ratio: 15.9 kW/t (55 kW / 3.5 t)

Power class: Universal (40–100 hp)

Stronger than 52% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Renault Ceres 85 X (A) have?

The Renault Ceres 85 X (A) delivers 75 hp.

How much does the Renault Ceres 85 X (A) weigh?

The unladen weight is 3,480 kg.

What engine does the Renault Ceres 85 X (A) have?

4 cylinders, 4,625 cm³ displacement, Diesel.

How fast does the Renault Ceres 85 X (A) go?

Top speed is 30 km/h.

What are the dimensions of the Renault Ceres 85 X (A)?

4,087 mm × 1,929 mm × 2,550 mm.

When was the Renault Ceres 85 X (A) built?

Production years: 11/1994–9/1998.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Check the weights in the papers against the figures here — attachments change them.
Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
Shift the gearbox cold and warm — jumps only show up at temperature.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
