Ra Pe GEO-3500 – specifications

Built: 2009-2011 · Series: Other models

The Ra Pe GEO-3500 is a car trailer from Ra Pe (EU vehicle class O2), built from 2009 to 2011. It is 5,345 mm long and 2,315 mm wide, weighs 770 kg unladen and has a permitted gross weight of 3,500 kg.

Data for the version built 2009-2011 · Data origin: Official register · sources

More machines from model year 2009

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

Payload for the Ra Pe GEO-3500, i.e. permitted gross weight minus unladen weight, is 2,730 kg. More than half of the gross weight is therefore available for cargo.

For the driving licence this means: category B allows combinations up to 3,500 kg, code 96 up to 4,250 kg permitted total mass. With a 3,500 kg trailer too little would remain for the towing vehicle even with code 96 – in practice a BE licence is needed, which covers trailers up to 3,500 kg. Being over 750 kg, the trailer must be braked, and the towing vehicle needs a braked towing capacity of at least 3,500 kg.

Among the 8 car trailers from Ra Pe with a stated length, the Ra Pe GEO-3500 at 5,345 mm is among the shortest (rank 8); the range runs from 5,345 to 8,020 mm. The Finnish vehicle register lists 2 units – one of the brand's most common models.

Ra-Pe – other models: collective page of trailers outside the named ranges, AT, ATU, GEO, UKJ, UPT and VT series, 660 to 1,170 kg unladen weight, a constant 3.5 t gross weight

This page gathers the Ra-Pe trailers the register could not assign to a named range. The AT, ATU, GEO, UKJ, UPT and VT series each carry the suffix 3500 or 35, denoting the permissible gross weight class in kilograms; only the type AT-350 departs from this scheme in its code.

Read on 3 more paragraphs

The register lists here 8 versions with unladen weights from 660 to 1,170 kg, a uniformly constant gross weight of 3,500 kg, lengths from 5,345 to 8,020 mm and widths from 2,050 to 2,560 mm.

With a uniform gross weight of 3.5 tonnes, the whole programme sits at the boundary of category O2, the classic field of braked tandem-axle trailers for transport, machinery and material haulage, which drivers with a regular category B licence can still tow in many countries. The uniform weight class points to a narrow model programme tailored to a single market segment, without outliers above or below. The solid, repeatedly duplicated construction of this class also makes it easier to compare offers from different sellers.

Buying used in this class, frame and axles matter most: corrosion on side members and axle mounts, the condition of the brakes and overrun system, tyre tread and the tightness of the load floor and side panels deserve inspection, together with registration papers. Parts for axles, brakes and lighting are available through the open trailer parts trade.

Sources: SpecCodex register, model data: Ra-Pe (weitere Modelle)

Technical data

Dimensions and weights

Length5,345 mmcorrect
Width2,315 mmcorrect
Unladen weight770 kgcorrect
Gross vehicle weight3,500 kgcorrect

Frequently asked questions

How much does the Ra Pe GEO-3500 weigh?

The unladen weight of the Ra Pe GEO-3500 is 770 kg.

What is the gross vehicle weight of the Ra Pe GEO-3500?

The gross vehicle weight of the Ra Pe GEO-3500 is 3,500 kg.

What are the dimensions of the Ra Pe GEO-3500?

Dimensions of the Ra Pe GEO-3500: length 5,345 mm, width 2,315 mm.

When was the Ra Pe GEO-3500 built?

The Ra Pe GEO-3500 was built from 2009 to 2011.

What to check before buying

  • Search the frame and welds at the axle mounts — that is where cracks start.
  • Check the brakes and the last inspection in the papers.
  • Work the gross weight against the towing vehicle before buying.
  • Compare the chassis number with the papers.
  • Look at the floor, cover or body from the inside — rust does not show from outside.

A general list for this type of machine — no substitute for an inspection or an appraiser.
