Qin Wei Electric AEEF-112M-2
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Qin Wei Electric – other models: the collective page of MEPS-registered three-phase motors outside the named ranges, frame sizes 80 to 315, 0.75 to 184 kW, manufactured in China and Taiwan
This page gathers the three-phase motors carried in the Australian energy-efficiency register under the Qin Wei Electric brand, which the register does not assign to a named range. The first digit of the IP rating denotes protection against solid objects, the second against water. The type designations show several parallel schemes: AEEF and AEHL with frame size and pole count (AEEF-112M-2, AEHL-132S-2), and MAE and MAE1 with an appended letter P for pole count (MAE-100L-4P, MAE1-160L-2P); the exact distinction between the individual ranges cannot be reliably established from the dump.
Read on 3 more paragraphs
The register lists here 82 versions with 0.75 to 184 kW, two- to six-pole, full-load efficiencies from 79.26 to 96.44% and at 75% load from 80.21 to 96.22%. Protection ratings range from plain IP55 through combinations with IP24/IP54/IP56 to combinations with IP21/IP22/IP23; frame sizes fall between 80 and 315 under IEC. Manufacturing countries recorded are China for the largest share, alongside combinations of Taiwan and China and Taiwan alone. Testing followed the 2012 and 2019 GEMS determinations. For 77 of the 82 motors a High Efficiency Level is documented: 14 reach the 2005 level, 1 the 2018 level, the remaining 62 no classification.
With outputs up to 184 kW and a wide spread of protection ratings, the page shows a comparatively demanding programme from the Chinese-Taiwanese manufacturing base, covering plain catalogue motors alongside versions built for harsher ambient conditions with higher protection ratings.
When buying used, what matters is bearing condition and a checked insulation resistance of the winding, visible overheating marks on the terminal box and fan cover, the condition of shaft and key, and a legible nameplate with frame size, pole count and efficiency class; for the higher-protection-rating versions it is also worth checking the seals at the terminal box and shaft exit. Spares depend on the distribution channel.
Sources: SpecCodex register, model data: Qin Wei Electric, Zulassungsdaten GEMS/MEPS (Australien)
Technical data
Engine
| Rated output | 4 kWcorrect |
|---|
Electrical data
| Rated voltage | 415 Vcorrect |
|---|---|
| Number of poles | 2correct |
| Protection class | IP55correct |
| Frame size | 112 M (foot)correct |
| Mounting (IEC 60034-7) | B3correct |
| Efficiency at full load | 89.31 %correct |
| Efficiency at 75 % load | 89.79 %correct |
| Efficiency at half load | 88.97 %correct |
Origin and approval
| Country of manufacture | Chinacorrect |
|---|
Other data
| Standard applied | Greenhouse and Energy Minimum Standards (Three Phase Electric Motors) Determination 2012correct |
|---|---|
| Test method | IEC 60034-2-1 (Edition 2.0)correct |
Frequently asked questions
How much power does the Qin Wei Electric AEEF-112M-2 have?
The Qin Wei Electric AEEF-112M-2 delivers 4 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 22 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
