Premium DG100L2-28-8
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
"Premium" – other models: the collective page of MEPS-registered three-phase motors outside the named ranges, frame sizes 100 to 280, 1.1 to 90 kW, 2- to 8-pole, manufactured in China
"Premium" is a manufacturer name carried in the Australian energy-efficiency register for three-phase motors; no further confirmed company data is available. This page gathers the motors registered under this name that the register (GEMS/MEPS) could not assign to a named range. The model designations, such as DG160L-42-6, DG100L2-28-8 or DG280S-65-2, start with the frame size (100 to 280) and a build-length code (S, L, L2, M1) and end with the pole count.
Read on 3 more paragraphs
The register lists here 5 versions with 1.1 to 90 kW rated output, two- to eight-pole, all at 400 V. Full-load efficiency ranges from 79.4 to 95.53%, and at 75% load from 79.4 to 95.41%. All five motors carry protection rating IP56, frame sizes run from 100 to 280. Testing followed the AS/NZS 1359.5:2004 standard with test method B; none of the five versions reaches a High Efficiency Level. The mounting form is identical across all five motors and covers practically the whole spectrum: B3, B5, B6, B7, B8, B14, B34, B35 and the vertical forms V1, V3, V4, V15, V18, V19 and V36.
With a span from 1.1 to 90 kW and pole counts from two to eight, the range covers a broad field of standard applications for pumps, fans, conveyors and compressors; the consistently identical IP56 protection and the wide mounting spectrum point to a versatile standard-motor range.
When buying used, bearing condition and a checked insulation resistance of the winding, the condition of shaft and key, the visible condition of the terminal box and fan cover, and a legible nameplate with frame size, pole count and mounting form matter, since no High Efficiency classification is available here as a reference point; anyone wanting to run the motor on a variable-speed drive should check its suitability beforehand. Spares run through the relevant distribution.
Sources: SpecCodex register, model data: Premium (weitere Modelle, MEPS-Registrierungen)
Technical data
Engine
| Rated output | 1.1 kWcorrect |
|---|
Dimensions and weights
| Weight | 41 kgcorrect |
|---|
Electrical data
| Rated voltage | 400 Vcorrect |
|---|---|
| Number of poles | 8correct |
| Protection class | IP56correct |
| Frame size | 100 L (foot)correct |
| Mounting (IEC 60034-7) | B3, B5, B6, B7, B8, B14, B34, B34, B35, V1, V3, V4, V15, V18, V19, V36correct |
| Efficiency at full load | 79.4 %correct |
| Efficiency at 75 % load | 79.4 %correct |
| Efficiency at half load | 76.6 %correct |
Origin and approval
| Country of manufacture | Chinacorrect |
|---|
Other data
| Standard applied | AS/NZS 1359.5:2004correct |
|---|---|
| Test method | AS/NZS 1359.102.3:2000correct |
Frequently asked questions
How much power does the Premium DG100L2-28-8 have?
The Premium DG100L2-28-8 delivers 1.1 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
