Peugeot/tensa BOXER
Built: 2020 · Series: Other models
More machines from model year 2020
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Peugeot Boxer Tensa (2020): oversize box body with 6,920 mm overall length on a Boxer chassis, 2.2-litre four-cylinder diesel and 3,500 kg gross weight
As part of the Sevel range, the Peugeot Boxer shares its technical base with the Fiat Ducato and Citroën Jumper and is built in Val di Sangro, Italy. Bodybuilders such as the Tensa name recorded here use the Boxer chassis for their own, usually extended, box bodies.
Read on 3 more paragraphs
The 2.2-litre four-cylinder diesel with 2,179 cc displacement is the stronger of the two Boxer engine options. At 3,500 kg gross vehicle weight and 2,551 kg kerb weight, the payload comes to around 950 kg. At 6,920 mm overall length on a 4,040 mm wheelbase, the body extends well beyond the chassis, while the 2,280 mm width shows the sideways overhang of a box body reaching out over the cab. Top speed is given as 160 km/h.
Despite an overall length of almost seven metres, the vehicle stays in EU category N1 at 3,500 kg gross vehicle weight and can be driven on a category B licence. Overlength bodies of this kind need a larger turning radius than standard panel vans when cornering or parking.
On a vehicle with such a long body, it is worth checking the rear overhang for distortion and the connection between the body frame and chassis for loose bolts or cracked paint. The 2.2-litre HDi engine needs attention to the turbocharger and intercooler hoses, whose leaks show up as loss of power. Tyres and brakes should be checked for even wear given the high kerb weight.
Sources: SpecCodex-Register: Kennwerte des Modells BOXER
Technical data
Engine
| Cylinders | 4correct |
|---|---|
| Displacement | 2,179 cm³correct |
Dimensions and weights
| Length | 6,920 mmcorrect |
|---|---|
| Width | 2,280 mmcorrect |
| Wheelbase | 4,040 mmcorrect |
| Unladen weight | 2,551 kgcorrect |
| Gross vehicle weight | 3,500 kgcorrect |
Drivetrain and chassis
| Wheels | 4correct |
|---|---|
| Top speed | 160 km/hcorrect |
Frequently asked questions
How much does the Peugeot/tensa BOXER weigh?
The unladen weight is 2,551 kg.
What is the gross vehicle weight of the Peugeot/tensa BOXER?
3,500 kg.
What engine does the Peugeot/tensa BOXER have?
4 cylinders, 2,179 cm³ displacement.
What are the dimensions of the Peugeot/tensa BOXER?
6,920 mm × 2,280 mm.
When was the Peugeot/tensa BOXER built?
Production years: 2020.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
