New Holland TG255 4WD – specifications

Series: Other models

Build year not documented · Data origin: Reference work (Wikipedia/Wikibooks), Directory data · sources

Source: smeq.ru

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The New Holland TG255 is a heavy-duty four-wheel-drive tractor produced in 2002. It belongs to the TG series and features a unitized frame design. The vehicle is powered by a six-cylinder diesel engine with turbocharging and charge air cooling. The design focuses on high traction and stability during demanding field operations.

The six-cylinder engine with a displacement of 8,275.5 cm³ delivers an output of 189.8 kW at a rated speed of 2,200 rpm. A torque rise of 60.6% allows peak loads to be overcome without gear shifting, which is crucial for tough soil conditions or heavy implements. With an empty weight of 13,381 kg, the mass ensures good traction and minimizes wheel slip in the field. The powershift transmission enables uninterrupted gear changes, increasing working speed during plowing or cultivating. The maximum speed of 40 km/h is sufficient for on-farm transport. The large tank with a capacity of 605.7 l ensures long operating times without frequent refueling stops.

Within the series, the TG255 is positioned as a high-performance model for large areas. The PTO output of 215 hp drives large implements such as mowers or manure spreaders. The dimensions of 5,775 mm in length and 3,048 mm in width require careful planning for farm access and transport. The turning radius of 5,090 mm determines maneuverability on small plots. The ground clearance of 350 mm protects the underside from damage caused by stones or uneven terrain.

New Holland – other models: the collective page of tractors outside the named ranges, from the Fiat heritage (80-66, 110-90) through the Ford 40 and 70 series (7740, 8340, 8670) to the 9x82 and T9, 14 to 457 kW, NEF

This page gathers the New Holland tractors the register could not assign to a named range – and it shows the brand's three roots: Fiat of Turin, Ford of Basildon and Versatile of Winnipeg. New Holland, founded in 1895 as a farm-machinery works in Pennsylvania, was joined with Ford Tractor in 1986 into Ford New Holland and bought by Fiat in 1991, which merged with Case as CNH from 1999; the blue tractors of the 1990s therefore carry three type logics. The Fiat types such as 80-66 and 110-90 give the hp class before and the series after the hyphen; the Ford 40 (5640 to 8340) and 70 (8670 to 8970) series from Basildon and Antwerp give the power in the middle digits and the series in the last, with SLE and SL as equipment lines; the articulated 9282 to 9882 and the later T9 come from Winnipeg and Fargo. From 2007 the T logic applies: T4 to T9 as ranges, the following digits as power (T6.140 about 140 hp). The engines are Fiat's 8000 series, Ford's Genesis, FPT's NEF and Cursor and Cummins in the articulated tractors.

Read on 3 more paragraphs

The register lists here 578 versions with 13.8 to 457 kW from three- to six-cylinders of 954 to 15,001 cm³, PTO outputs from 15 to 530 hp, lift capacities from 574 to 8,900 kg, unladen weights from 652 to 25,401 kg, gross weights from 3,000 to 18,000 kg, lengths from 2,700 to 8,005 mm and widths from 1,082 to 4,060 mm.

New Holland is Europe's second-largest tractor brand after John Deere and in the top three in Italy, Spain, France, Britain and Turkey; the brand also carries the specialist tractors from Jesi and the Boomer compact class from Japan.

On used tractors, clutch and shuttle count on Fiat types, electronics and powershift on the Ford 40 and 70 series, transmission and tyres on the articulated tractors, and on the T ranges operating hours, common-rail injection and exhaust aftertreatment; parts run through CNH.

Sources: SpecCodex register, model data: New Holland (weitere Modelle), New Holland Agriculture (manufacturer)

Technical data

Engine

Fueldieselcorrect
Power189.8 kWcorrect
Rated speed2,200 rpmcorrect
Rated speed2.200/mincorrect
Cylinders6correct
Cylinders6 Hubraumcorrect
Displacement8,275.5 cm³correct
AspirationTurbocharged, air-to-air intercooledcorrect
Cooling systemwater-cooledcorrect
Torque rise60, 6 %correct

Dimensions and weights

Length5,775 mmcorrect
Width3,048 mmcorrect
Height3,175 mmcorrect
Wheelbase3,078 mmcorrect
Ground clearance350 mmcorrect
Unladen weight13,381 kgcorrect

Drivetrain and chassis

Gearbox typepowershift transmissioncorrect
Top speed40 km/hcorrect
Turning radius5,090 mmcorrect
Drive typeall-wheel drivecorrect
Construction typeunit construction (no separate frame)correct

Working data

Fuel tank capacity605.7 lcorrect

Origin and approval

Production period2,002correct
Type6 TAAcorrect

Other data

PTO output215 hpcorrect
Steer9,718correct
Triebwerk1.Gangcorrect

Where this model stands

Power-to-weight ratio: 14.2 kW/t (190 kW / 13.4 t)

Power class: Heavy (> 180 hp)

Stronger than 95% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the New Holland TG255 have?

The New Holland TG255 delivers 190 kW.

How much does the New Holland TG255 weigh?

The unladen weight is 13,381 kg.

What engine does the New Holland TG255 have?

6 cylinders, 8,276 cm³ displacement, Diesel.

How fast does the New Holland TG255 go?

Top speed is 40 km/h.

What is the PTO output of the New Holland TG255?

PTO output is 215 hp.

What are the dimensions of the New Holland TG255?

5,775 mm × 3,048 mm × 3,175 mm.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
