New Holland E195EL
Series: New Holland Hydraulic Excavator
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
New Holland Hydraulic Excavator E130 to E485: from B-generation to C-generation crawler excavators, 60 to 344 kW, 12.8 to 79 t operating weight, Tier 4 Final without a particulate filter
New Holland Construction builds its crawler excavators with Japan's Kobelco, which is why the line is often labeled New Holland Kobelco. The "New Holland Hydraulic Excavator" bucket here groups 35 live-listed E-Series models, from the compact E130 up to the large E485.
Read on 3 more paragraphs
The number after the E corresponds roughly to size class and operating weight: across all 35 models, operating weight ranges from 12,800 to 79,000 kg, with engine output from 60 to 344 kW. The letter after it marks the generation – the B-Series was followed by the C-Series, which the manufacturer states delivers roughly 5% more power. Suffixes like SR (Short Reach, a shorter tail swing for confined sites) mark further variants.
Tier 4 Final emissions standards marked a turning point: newer models meet it via cooled exhaust gas recirculation and a diesel oxidation catalyst, without a particulate filter. Displacement (3,900 to 15,600 cm³) and cylinder count (4 to 6) are recorded for over 30 models, torque (390 to 998 Nm) for 16.
Buying used, pay attention to boom and dipper bushings, undercarriage track condition, and the tightness of the main and swing pumps. Models such as E130, E175, E215 and E385 appear regularly in the listed inventory – but the trailing number alone says nothing about build year; that's what the serial plate is for.
Sources: Kennwerte der Modelle New Holland Hydraulic Excavator, – Ohne Dieselpartikelfilter: Abgasnorm Tier 4 Final bei Raupenbaggern erreicht, – Kettenbagger Kurzheck Kobelco, New Holland E200 SR (Beispielangebot, SR/C-Serie)
Technical data
Engine
| Engine model | CNH F4BE0484D*D608correct |
|---|---|
| Power | 96.9 kWcorrect |
| Rated speed | 2,200 rpmcorrect |
| Torque | 450.1correct |
| Speed at max. torque | 1,400 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 3,900.1 cm³correct |
| Aspiration | turbocharged and intercoolercorrect |
| Coolant capacity | 18.2 lcorrect |
| Engine oil capacity | 15.1 lcorrect |
Dimensions and weights
| Ground clearance | 484.6correct |
|---|---|
| Unladen weight | 18,730 kgcorrect |
Working data
| Pump flow | 352 l/mincorrect |
|---|---|
| Hydraulic oil capacity | 150.3 lcorrect |
| Hydraulic pressure | 343 barcorrect |
| Fuel tank capacity | 165 lcorrect |
Other data
| Cab height | 2,984correct |
|---|---|
| System voltage | 24 Vcorrect |
Where this model stands
Power-to-weight ratio: 5.2 kW/t (97 kW / 18.7 t)
Stronger than 40% of the excavators & compaction in the register — out of 1,666 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the New Holland E195EL have?
The New Holland E195EL delivers 96.9 kW.
How much does the New Holland E195EL weigh?
The unladen weight is 18,730 kg.
What engine does the New Holland E195EL have?
4 cylinders, 3,900 cm³ displacement.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
