Moxy MT51

Series: Moxy Articulated Dump Truck

Source: https://www.alamy.com/stock-photo-moxy-mt41-articulated-dump

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Moxy MT51 belongs to the Moxy Articulated Dump Truck series. The engine delivers 509.9 hp (375 kW), has 6 cylinders, with a displacement of 15,000.7 cm³. The wheelbase measures 5,361.4 mm. Ground clearance is 637 mm. Top speed is 54.1 km/h. The tank holds 600.4 litres. The gearbox has 6 forward gears. The hydraulic tank holds 250.2 litres. The cooling system holds 75.3 litres. The oil fill is 45 litres. The electrical system runs on 24 V. The engine fitted is the QSX15. Tyre size: 29,5R25. The Moxy Articulated Dump Truck series covers 5 models. Rated output within it ranges from 318.2 to 509.9 hp; the MT51 sits at the top of that range with 509.9 hp. Its immediate neighbours are the MT41 below it with 450.1 hp. 5 Moxy models are on record. The model is listed under Mining equipment. 19 verified figures from 1 source are on file.

Technical data

Engine

Engine model	QSX15correct
Power	509.9 hp (375 kW)correct
Cylinders	6correct
Displacement	15,000.7 cm³correct
Aspiration	turbochargedcorrect
Coolant capacity	75.3 lcorrect
Engine oil capacity	45 lcorrect

Dimensions and weights

Length	10,677.1correct
Width	3,477.8correct
Wheelbase	5,361.4correct
Ground clearance	637correct

Drivetrain and chassis

Gearbox type	Allison 4600 ORS automatic gearboxcorrect
Forward gears	6correct
Tyre size	29.5R25correct
Top speed	54.1 km/hcorrect
System voltage	24 Vcorrect

Working data

Hydraulic oil capacity	250.2 lcorrect
Fuel tank capacity	600.4 lcorrect

Frequently asked questions

How much power does the Moxy MT51 have?

The Moxy MT51 delivers 510 hp.

What engine does the Moxy MT51 have?

6 cylinders, 15,001 cm³ displacement.

How fast does the Moxy MT51 go?

Top speed is 54.1 km/h.

What are the dimensions of the Moxy MT51?

10,677 mm × 3,478 mm.

What to check before buying

Check the hour meter against the service records — a replaced instrument is the most common gap.
Compare the data plate and chassis number with the papers.
Load the hydraulics and watch for sag.
Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
