Moto Technik CDF11/B3/4
Series: CDF1.1 B3
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Moto-Technik CDF1.1/B3 – three-phase standard motors from China: B3 foot mounting, frame sizes 90 to 160, 1.1 to 11 kW, 2- to 6-pole, IP55 protection, efficiency up to 88.9%
Moto-Technik sells three-phase standard motors in foot-mounted form (B3) under the CDF range, registered on the Australian energy-efficiency register MEPS. The type designation, for example CDF1.1/B3/4 or CDF11/B3/6, combines the power code before the slash with the B3 mounting form and the pole count as the last digit; the pole count matches the 2 to 6 range carried in the register.
Read on 3 more paragraphs
The register lists here 6 versions with 1.1 to 11 kW rated output, 2- to 6-pole, at a voltage of 415 V. Full-load efficiency ranges from 75.2 to 88.9%, and at 75% load from 75.6 to 88.85%. Frame sizes run from 90 to 160, and all six motors carry IP55 protection. Testing followed the legacy standard AS/NZS 1359.5:2000 using test method B.
As a simple foot-mounted standard-motor programme, the CDF1.1/B3 range covers the basic demand for three-phase induction motors for pumps, fans and conveyors, where the B3 form is the standard mounting position. The range is manufactured in China.
When buying used, what matters is bearing condition and a checked insulation resistance of the winding, visible overheating marks on the terminal box and fan cover, and a legible nameplate with frame size, pole count and protection rating. The mounting codes B3, B5, B14, B34 and B35 show the motors can also be fitted in other positions via adapters. Spares run through the relevant distributor.
Sources: SpecCodex register, model data: Moto-Technik CDF1.1/B3
Technical data
Engine
| Rated output | 11 kWcorrect |
|---|
Dimensions and weights
| Weight | 123 kgcorrect |
|---|
Electrical data
| Rated voltage | 415 Vcorrect |
|---|---|
| Number of poles | 4correct |
| Protection class | IP55correct |
| Frame size | 160 M (foot)correct |
| Mounting (IEC 60034-7) | B3, B5, B14, B35, B34correct |
| Efficiency at full load | 88.9 %correct |
| Efficiency at 75 % load | 88.85 %correct |
| Efficiency at half load | 87.85 %correct |
Origin and approval
| Country of manufacture | Chinacorrect |
|---|
Other data
| Standard applied | AS/NZS 1359.5:2000 (Legacy)correct |
|---|---|
| Test method | AS 1359.102.1:1997correct |
Frequently asked questions
How much power does the Moto Technik CDF11/B3/4 have?
The Moto Technik CDF11/B3/4 delivers 11 kW.
What to check before buying
- Match the data plate against the order: frame size, mounting and rating have to agree.
- Check the ingress rating against the installation site — outdoors or in dust the demands differ.
- Hold the mounting form and dimensions against the existing seat before ordering.
- The pole count sets the speed — when replacing an older unit, compare this first.
- For used units, ask about winding condition and bearing play.
- Ask about parts availability for this series — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
