Mim Mak CDT99
Built: 2020 · Series: Other models
More machines from model year 2020
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
CDT99 – EU class O2 single-axle trailer with a 3,500 kg gross weight, 780 kg kerb weight, 2,820 mm wheelbase and 2,720 kg payload
The CDT99 is a single-axle trailer with a gross weight of 3,500 kg, placing it at the upper edge of EU class O2, the bracket up to 3,500 kg where overrun brakes are the standard technology. Trailers of this size can be towed on a category B licence as long as the combination's gross weight stays under the relevant limit, otherwise the BE extension is required.
Read on 3 more paragraphs
At a kerb weight of 780 kg and a payload of 2,720 kg, the CDT99 carries more than three times its own weight in cargo. The body length of 3,950 mm and width of 2,400 mm on two wheels describes a compact but wide trailer. The 2,820 mm wheelbase, on a single axle, corresponds to the distance between the coupling and the axle and gives a balanced weight distribution on the drawbar.
Single-axle trailers of this type are slowed by an overrun brake, triggered through the overrun mechanism on the drawbar when the towing vehicle brakes. With a payload-to-kerb-weight ratio like this, correct noseweight setting matters especially, so as not to overload the towing vehicle's hitch.
When buying used, the overrun mechanism and hitch head are among the first checkpoints: play, corrosion and the function of the reverse lock-out should be checked. The brake linings and their linkage deserve a look, as does the jockey wheel mechanism. At such a low kerb weight, frame corrosion often shows up first on the thinner profiles around the axle mount.
Sources: SpecCodex-Register: Kennwerte des Modells CDT99
Technical data
Dimensions and weights
| Length | 3,950 mmcorrect |
|---|---|
| Width | 2,400 mmcorrect |
| Wheelbase | 2,820 mmcorrect |
| Unladen weight | 780 kgcorrect |
| Gross vehicle weight | 3,500 kgcorrect |
Drivetrain and chassis
| Wheels | 2correct |
|---|---|
| Top speed | 100 km/hcorrect |
Frequently asked questions
How much does the Mim Mak CDT99 weigh?
The unladen weight is 780 kg.
What is the gross vehicle weight of the Mim Mak CDT99?
3,500 kg.
Up to what speed is the Mim Mak CDT99 approved?
Approved up to 100 km/h.
What are the dimensions of the Mim Mak CDT99?
3,950 mm × 2,400 mm.
When was the Mim Mak CDT99 built?
Production years: 2020.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 10 individual figures for this model. They come from 2 recorded sources; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
