Merk Pullax P 30
Series: Pullax
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Merk Pullax – the P20, P 30 and P 40 models with two- to four-cylinder diesel engines, 15.7 to 30 kW and a type designation based on approximate horsepower
The Pullax range comprises the Pullax P20, Pullax P 30 and Pullax P 40 models. The type designation follows the practice common among small tractors of the period of carrying the approximate engine output directly in the model name: the P20 is close to 21 hp, the P 40 close to 42 hp.
Read on 3 more paragraphs
The register lists 3 versions with 15.7 to 30 kW (21.4 to 42 hp) from two- to four-cylinders of 1,145 to 2,290 cc displacement at rated speeds between 2,500 and 2,700 rpm. Operating weight ranges from 1,430 to 4,200 kg, length from 4,400 to 5,900 mm, width from 1,690 to 1,800 mm and height from 1,420 to 1,600 mm. All three models run on diesel.
The wide span of weight and length across the three models shows that the Pullax range covered a broad output spectrum, from a light small tractor to a markedly larger, heavier version, rather than being confined to a single vehicle class. The consistent diesel fitment across all three models sets the range apart from many contemporary petrol or dual-fuel tractors from smaller makers.
On a used purchase of these historic diesel tractors, points to check include the condition of the injection pump and nozzles, the tightness of the radiator and fuel lines, wear on the clutch and gearbox, and corrosion on the chassis and sheet-metal parts. Spare parts for this little-known brand are found mainly through collector markets for farm machinery.
Sources: SpecCodex register, model data: Merk Pullax
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 30 hp (22 kW)correct |
| Rated speed | 2,500 rpmcorrect |
| Cylinders | 2correct |
| Displacement | 1,558 cm³correct |
| Cooling | air-cooledcorrect |
Dimensions and weights
| Length | 4,400 mmcorrect |
|---|---|
| Width | 1,790 mmcorrect |
| Height | 1,420 mmcorrect |
| Wheelbase | 1,800 mmcorrect |
| Unladen weight | 4,200 kgcorrect |
Drivetrain and chassis
| Gearbox | 8V/4Rcorrect |
|---|---|
| Forward gears | 4correct |
| Reverse gears | 4correct |
| Front tyres | 10, 5 x 18correct |
| Rear tyres | 10, 5 x 18correct |
| Top speed | 19 km/hcorrect |
Origin and approval
| Construction | Motorkarre für Kommune, Landwirtschaft und Forstwirtschaftcorrect |
|---|---|
| Units built | ca. 35correct |
Where this model stands
Power-to-weight ratio: 5.2 kW/t (22 kW / 4.2 t)
Power class: Compact (< 40 hp)
Stronger than 16% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Merk Pullax P 30 have?
The Merk Pullax P 30 delivers 30 hp.
How much does the Merk Pullax P 30 weigh?
The unladen weight is 4,200 kg.
What engine does the Merk Pullax P 30 have?
2 cylinders, 1,558 cm³ displacement, Diesel.
How fast does the Merk Pullax P 30 go?
Top speed is 19 km/h.
What are the dimensions of the Merk Pullax P 30?
4,400 mm × 1,790 mm × 1,420 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
