Mercedes Benz U4023
Built: 2013 · Series: U437.4
More machines from model year 2013
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Mercedes-Benz U 437.4: the Unimog U4023 is a four-cylinder implement carrier with a 5,132 cm³ engine, 231 hp (170 kW) at 2,200 rpm, a top speed of 89 km/h and a weight of 7,500 kg, built in 2013
At Mercedes-Benz, the Unimog has stood for an off-road universal implement carrier since the 1950s. The U4023 in the U 437.4 series belongs to the heavy Unimog generation of the 2010s, built for tasks demanding high off-road capability and heavy payloads.
Read on 3 more paragraphs
The four-cylinder engine displaces 5,132 cm³ and produces 231 hp, or 170 kW, at 2,200 rpm, delivering 900 Nm of torque, and is water-cooled. On a 3,850 mm wheelbase the U4023 weighs 7,500 kg. With a top speed of 89 km/h it reaches, despite its weight and off-road ability, a high road speed for an implement carrier.
The heavy U 437 series combines portal axles and long suspension travel with a powerful four-cylinder turbodiesel, making it as suited to extreme off-road use, disaster relief and fire service as to heavy attachments in agriculture and municipal work. The frame is designed to flex so that all four wheels keep ground contact on rough terrain, and power take-offs and hydraulic couplings front and rear allow continuous work with changing attachments.
When buying a used example, check the condition of the portal axle gearboxes and their differential locks, the tightness of the hydraulics for attachments, rust on the torsionally stiff frame, and the ratio of engine hours to mileage. Spare parts are readily available through the Mercedes-Benz Unimog network.
Sources: SpecCodex-Register: Kennwerte des Modells U4023, Mercedes-Benz
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 231 hp (170 kW)correct |
| Rated speed | 2,200 rpmcorrect |
| Torque | 900 Nmcorrect |
| Cylinders | 4correct |
| Displacement | 5,132 cm³correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Wheelbase | 3,850 mmcorrect |
|---|---|
| Ground clearance | 500 mmcorrect |
| Unladen weight | 7,500 kgcorrect |
Drivetrain and chassis
| Drive | four-wheel drivecorrect |
|---|---|
| Gearbox | 8 Gang Automatik UG 100/8correct |
| Forward gears | 8correct |
| Reverse gears | 6correct |
| Top speed | 89 km/hcorrect |
Origin and approval
| Construction | Kurzhaubercorrect |
|---|
Where this model stands
Power-to-weight ratio: 22.7 kW/t (170 kW / 7.5 t)
Power class: Heavy (> 180 hp)
Stronger than 94% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Mercedes Benz U4023 have?
The Mercedes Benz U4023 delivers 231 hp.
How much does the Mercedes Benz U4023 weigh?
The unladen weight is 7,500 kg.
What engine does the Mercedes Benz U4023 have?
4 cylinders, 5,132 cm³ displacement, Diesel.
How fast does the Mercedes Benz U4023 go?
Top speed is 89 km/h.
When was the Mercedes Benz U4023 built?
Production years: 2013.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 18 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
