Meert M36/3AL/D – specifications
Built: 1992 · Series: Other models
The Meert M36/3AL/D is a vehicle built by Meert. Production: 1992. The vehicle is 14,000 mm long and 2,600 mm wide. The unladen weight is 19,220 kg. The wheelbase measures 9,200 mm. Top speed is 100 km/h. The gross vehicle weight is 36,000 kg. Unladen weight across the Meert range ranges from 4,130 to 19,220 kg; the M36/3AL/D sits at the top of that range with 19,220 kg. Its immediate neighbours are the MEERT below it with 9,685 kg. Gross vehicle weight across the Meert range ranges from 16,000 to 36,000 kg; here the M36/3AL/D sits at the top of that range with 36,000 kg. 3 Meert models are on record.
Data for the version built 1992 · Data origin: Official register · sources
More machines from model year 1992
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Meert – other models: the collective page of trailers outside the named ranges, AW/2MA/20/15 and M36/3AL/D, unladen weights from 4,130 to 19,220 kg, gross weights from 16,000 to 36,000 kg
This page gathers the Meert trailers the register could not assign to a named range. The type designations AW/2MA/20/15 and M36/3AL/D do not follow any logic that can be resolved from the register; at lengths up to 14 metres and gross weights up to 36 tonnes, these are heavy semi-trailer chassis for heavy-haul and machinery transport.
Read on 3 more paragraphs
The register lists here 3 versions with unladen weights from 4,130 to 19,220 kg, gross weights from 16,000 to 36,000 kg, lengths from 8,950 to 14,000 mm and widths from 2,470 to 2,600 mm.
Semi-trailers of this weight class carry construction machinery, steel or concrete parts and other heavy loads in European long-haul transport; the width of up to 2.60 m matches the maximum allowed on the public road without a special permit. The wide spread of unladen and gross weight within just a few models shows that the range runs from single-axle auxiliary semi-trailers to multi-axle low-loaders.
On a used heavy-haul semi-trailer, the condition of frame and main beams for cracks and deformation, the function of axles, brakes and, where fitted, steering axles, the condition of the hydraulics on lowering versions, and a complete test history matching the high gross weight all count. Before buying it is also worth clarifying whether a special permit for oversize or overweight loads is needed for the particular cargo.
Sources: SpecCodex register, model data: Meert (weitere Modelle)
Technical data
Dimensions and weights
| Length | 14,000 mmcorrect |
|---|---|
| Width | 2,600 mmcorrect |
| Coupling-to-axle distance | 9,200 mmcorrect |
| Unladen weight | 19,220 kgcorrect |
| Gross vehicle weight | 36,000 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 8 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Are you the manufacturer or a dealer of this machine? Check the data and add missing figures — we mark your correction as manufacturer or dealer information.
Check and complete the data →Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
Other models in this series
Sources: RDW — Dutch national vehicle register (retrieved August 2026) · Data sources and cross-checks
