McCormick SUPER-BMD
Built: 1953–1959 · Series: Super
More machines from model year 1953
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
McCormick Super – the range page of the IH Doncaster classics of the 1950s and 1960s, from the Super BM to the Super FCC Vineyard, 31.6 to 37.7 kW, IH four-cylinders
This page gathers the versions of the McCormick Super range, built by International Harvester at the Doncaster plant in England in the 1950s and 1960s. The letter suffixes BM, BMD, BWD-6 and Cub distinguish body and drive variants of the range, the Super FCC Vineyard is the narrow version for viticulture; besides diesel, petrol and the petrol/TVO (Tractor Vaporising Oil) combination are also recorded as fuel, a fuel type typical of British post-war tractors.
Read on 3 more paragraphs
The register lists here 10 versions with 31.6 to 37.7 kW (43 to 51 hp) from four-cylinders of 4,324 to 4,326 cm³ displacement, unladen weights of 2,450 to 2,562 kg, lengths of 3,175 to 3,510 mm, widths of 1,765 to 2,159 mm and heights of 1,676 to 1,989 mm. International and International Harvester (Great Britain) are recorded as engine makers, with the engine type IH BC 264.
The Super range is among the well-known IH Doncaster classics of those years, with which International Harvester competed in Britain and the Commonwealth against Ferguson, Fordson and David Brown; the name parts Cub and Vineyard refer to the model family and the special version for narrow vine rows respectively.
On these classics, engine and fuel system condition – on petrol/TVO versions especially the switch-over valve – clutch and gearbox, rust on bodywork and mudguards, and the originality of ancillary parts count; parts run through dealers specialising in IH classics.
Sources: SpecCodex register, model data: McCormick Super, International Harvester (Wikipedia)
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 47 hp (34.6 kW)correct |
| Rated speed | 1,450 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 4,326 cm³correct |
| Bore | 101.6 mmcorrect |
| Stroke | 133.35 mmcorrect |
| Compression ratio | 16.8correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 3,510 mmcorrect |
|---|---|
| Width | 2,159 mmcorrect |
| Height | 1,989 mmcorrect |
| Wheelbase | 2,390 mmcorrect |
| Ground clearance | 521 mmcorrect |
| Unladen weight | 2,475 kgcorrect |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | 5 V/1 Rcorrect |
| Forward gears | 5correct |
| Reverse gears | 1correct |
| Front tyres | 6.50-16correct |
| Rear tyres | 12-38correct |
| Top speed | 26 km/hcorrect |
Working data
| Fuel tank capacity | 75.7 lcorrect |
|---|
Origin and approval
| Construction | semi-frame constructioncorrect |
|---|---|
| Units built | 7,811correct |
Where this model stands
Power-to-weight ratio: 14 kW/t (35 kW / 2.5 t)
Power class: Universal (40–100 hp)
Stronger than 31% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the McCormick SUPER-BMD have?
The McCormick SUPER-BMD delivers 47 hp.
How much does the McCormick SUPER-BMD weigh?
The unladen weight is 2,475 kg.
What engine does the McCormick SUPER-BMD have?
4 cylinders, 4,326 cm³ displacement, Diesel.
How fast does the McCormick SUPER-BMD go?
Top speed is 26 km/h.
What are the dimensions of the McCormick SUPER-BMD?
3,510 mm × 2,159 mm × 1,989 mm.
When was the McCormick SUPER-BMD built?
Production years: 1953–1959.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
