Mccormick Deering MD/MDV

Built: 1/1941–3/1952 · Series: FARMALL-LETTERS-Baureihe

More machines from model year 1941

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The MD/MDV from Mccormick Deering is part of the FARMALL-LETTERS series. Production: 1/1941–3/1952. The engine delivers 35 hp (25.7 kW), has 4 cylinders, with a displacement of 4,059 cm³. Rated speed is 1,450 rpm. The machine is 3,219 mm long, 2,134 mm wide and 1,988 mm high. The unladen weight is 2,404 kg. The wheelbase measures 2,292 mm. Ground clearance is 648 mm. Top speed is 26 km/h. Transmission: 5 V/1 R. The engine is water-cooled. Tyres: front 6.00 x 16 (MDV: 6.00 x 20), rear 11 x 38 (MDV: 10.00 x 36). The fuel is diesel. The bore measures 98.43 mm. The stroke is 133.35 mm. The compression ratio is 14.2:1. Construction: semi-frame construction. Around 18.253 (MDV: 509) units were built. The FARMALL-LETTERS-Baureihe series covers 5 models. Rated output within it ranges from 19 to 37 hp; the MD/MDV sits at the top of that range with 35 hp. Its immediate neighbours are the H/HV below it with 26 hp and the M/MV above it with 37 hp. Unladen weight within it ranges from 830 to 2,404 kg; here the MD/MDV sits at the top of that range with 2,404 kg. 58 Mccormick Deering models across 9 series are on record.

McCormick-Deering Farmall Letters range – five tractors from the A/AV to the MD/MDV, built 1939 to 1954, four-cylinder engines of 1,853 to 4,059 cm³, 14 to 27.2 kW

The Farmall Letters range was the generation of International Harvester tractors built from 1939 to 1954 with letter-based type designations; the register lists here the A/AV, B/BN, H/HV, M/MV and MD/MDV. The V suffix denoted versions with raised ground clearance for row crops such as vegetables, MD/MDV the diesel variant of the large M.

Read on 3 more paragraphs

The register lists here five versions with 14 to 27.2 kW from four-cylinder engines of 1,853 to 4,059 cm³ displacement, unladen weights from 830 to 2,404 kg, lengths from 2,699 to 3,381 mm, widths from 1,419 to 2,146 mm and heights from 1,607 to 1,988 mm at speeds of 1,400 to 1,650 rpm; the models mostly ran on distillate, kerosene or petrol engines, the MD/MDV on diesel.

The Farmall Letters series, with its distinctive design by industrial designer Raymond Loewy and its graduated model range from A to M, shaped the North American tractor market of the post-war period and became a template for numerous competing models from other makers.

When buying used, the condition of the cylinder head and carburettor, or the injection pump on the MD/MDV, wear on the clutch and gearbox and corrosion on sheet-metal parts and wings matter; spare parts are comparatively well available thanks to the high production numbers and an active collector scene. Original paint and decals, where preserved, are particularly prized by collectors and are worth documenting before any restoration work.

Sources: SpecCodex register, model data: McCormick-Deering Farmall-Letters-Baureihe

Technical data

Engine

Fueldieselcorrect
Power35 hp (25.7 kW)correct
Rated speed1,450 rpmcorrect
Cylinders4correct
Displacement4,059 cm³correct
Bore98.43 mmcorrect
Stroke133.35 mmcorrect
Compression ratio14.2correct
Coolingwater-cooledcorrect

Dimensions and weights

Length3,219 mmcorrect
Width2,134 mmcorrect
Height1,988 mmcorrect
Wheelbase2,292 mmcorrect
Ground clearance648 mmcorrect
Unladen weight2,404 kgcorrect

Drivetrain and chassis

Driverear-wheel drivecorrect
Gearbox5 V/1 Rcorrect
Front tyres6.00 x 16 (MDV: 6.00 x 20)correct
Rear tyres11 x 38 (MDV: 10.00 x 36)correct
Top speed26 km/hcorrect

Origin and approval

Constructionsemi-frame constructioncorrect
Units built18.253 (MDV: 509)correct

Where this model stands

Power-to-weight ratio: 10.7 kW/t (26 kW / 2.4 t)

Power class: Compact (< 40 hp)

Stronger than 21% of the tractors in the register — out of 15,663 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Mccormick Deering MD/MDV have?

The Mccormick Deering MD/MDV delivers 35 hp.

How much does the Mccormick Deering MD/MDV weigh?

The unladen weight is 2,404 kg.

What engine does the Mccormick Deering MD/MDV have?

4 cylinders, 4,059 cm³ displacement, Diesel.

How fast does the Mccormick Deering MD/MDV go?

Top speed is 26 km/h.

What are the dimensions of the Mccormick Deering MD/MDV?

3,219 mm × 2,134 mm × 1,988 mm.

When was the Mccormick Deering MD/MDV built?

Production years: 1/1941–3/1952.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
  • Shift the gearbox cold and warm — jumps only show up at temperature.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
