Fiat Ducato Maxi L4H2 – specifications
Built: 2024 · Series: Other models
Data for the version built 2024 · Data origin: Directory data · sources
More machines from model year 2024
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Fiat Ducato – other models: the collective page of Ducato versions outside the named ranges, from the 30 140 L2H2 and 35 140 L2H1 to the Maxi L5H3, four-cylinder diesels of 1,956 to 2,999 cm³
This page gathers the Fiat Ducato versions the register could not assign to a named range, including type designations such as 30 140 L2H2 3450, 35 140 L2H1, 35 L3H2 140 Multijet and the long version 35 Maxi L4H2/L5H3. The Ducato's type logic combines the weight class (30, 33, 35, 40 for 3.0 to 4.0 tonnes), engine power in hp (140, 180) and the length and height of the body (L1 to L5, H1 to H3), with Maxi marking chassis reinforced to 4.0 tonnes.
Read on 3 more paragraphs
The register lists here 9 versions with 1,956 to 2,999 cm³ displacement from four cylinders, kerb weights from 1,660 to 3,144 kg, gross weights from 3,040 to 3,500 kg, a length of around 6,800 mm on the long bodies and widths from 2,200 to 2,400 mm.
The Fiat Ducato, together with its technically largely identical sister models, is one of Europe's best-selling large vans and, as a panel van, platform cab, chassis cab and motorhome base, covers practically every market segment of light commercial vehicles above 3.0 tonnes.
On a used Ducato of these versions, rust on the sills, wheel arches and load-bed floor, the condition of the Multijet turbodiesel and its exhaust aftertreatment, the behaviour of clutch and gearbox, and, on long versions and the Maxi chassis, frame reinforcement and the tow hitch all count; parts are widely available through the dense Fiat and Stellantis network.
Sources: SpecCodex register, model data: Fiat Ducato (weitere Modelle), Fiat Professional (manufacturer)
Technical data
Dimensions and weights
| Unladen weight | 2,255 kgcorrect |
|---|---|
| Gross vehicle weight | 3,500 kgcorrect |
| Cargo length | 4,070 mmcorrect |
| Cargo width | 1,870 mmcorrect |
| Cargo height | 1,932 mmcorrect |
Other data
| Anzahl der Vorbesitzer | 1correct |
|---|---|
| Aufbau | Kasten Hochraum Standardcorrect |
| Colour | whitecorrect |
| Emissionsklasse | Euro6correct |
| Equipment | ABScorrect |
| Fahrassistenz-System | Überschlag-Schutzsystemcorrect |
| Fahrzeugnummer | EULW1880correct |
| Getriebetyp | Automatischcorrect |
| Kraftstofftank | 90 Ltr.correct |
| Kraftstofftyp | dieselcorrect |
| Leistung | 132 kW (179,47 PS)correct |
| Payload | 1,245 kgcorrect |
| Polsterung | Stoffcorrect |
| Sitze im Fahrerhaus | Fahrersitz mit Armlehne und Lendenwirbelstützecorrect |
Used listings – figures from public listings
Between April and November 2026, speccodex recorded 16 public used-machine listings for Fiat Ducato Maxi L4H2 on 2 platforms. Asking prices ranged from €21,500 to €25,990 (median €22,990), year of manufacture 2024.
Offered mainly in Germany (90%) and Austria (10%); shares refer to listings that state a location.
Asking prices are sellers' demands, not achieved sale prices. Basis: public listings, recorded and analysed by speccodex. As of: 11 Nov 2026. Sellers usually do not state whether prices are net or gross.
Area: Machines › Commercial vehicles › Vans › Panel vans
Frequently asked questions
How much does the Fiat Ducato Maxi L4H2 weigh?
The unladen weight is 2,255 kg.
What is the gross vehicle weight of the Fiat Ducato Maxi L4H2?
3,500 kg.
When was the Fiat Ducato Maxi L4H2 built?
Production years: 2024.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 19 individual figures for this model. They come from 5 recorded sources; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Are you the manufacturer or a dealer of this machine? Check the data and add missing figures — we mark your correction as manufacturer or dealer information.
Check and complete the data →Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
