Massey Harris 30
Built: 1946-1952 · Series: Other models
← Predecessor: 101 Junior
More machines from model year 1946
Massey Harris – other models: collective page of tractors outside the named ranges, from the Big Bull to the Pony and Pacer, 8.2 to 34 kW, kerosene, petrol and diesel engines
This page gathers the Massey Harris tractors the register could not assign to a named range – from early large tractors such as the Big Bull to the compact post-war Pony and Pacer models. Massey Harris was formed in 1891 from the merger of the Canadian farm-equipment makers Massey and Harris in Toronto, before the company merged in 1953 with Harry Ferguson's tractor firm to form Massey-Ferguson. TWIN POWER-CHALLENGER and TWIN POWER-PACEMAKER refer to the engageable two-speed PTO reduction. The entry TE-A-20 belongs to the licence-built Ferguson TE-20, briefly sold under the Massey name too in the transitional years after the merger.
Read on 3 more paragraphs
The register lists here 29 versions with 8.2 to 34 kW from two- to six-cylinder engines of 1,021 to 11,403 cm³, unladen weights of 857 to 5,352 kg, lengths of 2,520 to 4,394 mm, widths of 1,422 to 2,075 mm and heights of 1,346 to 2,080 mm; rated speeds range from 750 to 1,800 rpm. Engines came from Massey Harris itself, from Continental and Perkins, and from Chrysler; many early models were started on petrol and switched to cheaper kerosene once warm.
Between the world wars and through the 1940s Massey Harris was among the leading tractor makers of North America and Britain; the sturdy Pony and Pacer tractors served as affordable entry models and were exported to Europe too. The merger into Massey-Ferguson in 1953 ended independent model development.
When buying used, the condition of the cooling system and head gasket, rust on the mudguards and toolbox, and the function of the mechanical PTO and belt pulley matter most. Parts for Massey Harris engines often overlap with early Massey-Ferguson and Ferguson stock; wiring and the carburettor are the most common weak points on the older petrol and kerosene models.
Sources: SpecCodex register, model data: Massey Harris (weitere Modelle)
Technical data
Engine
| Engine make | Continental Motors Companycorrect |
|---|---|
| Engine model | Continental - F162correct |
| Fuel | Gasoline G; Kerosene Kcorrect |
| Power | 25 @ 1500; 33 @1800 hp (17 / 22 kW)correct |
| Cylinders | 4correct |
| Displacement | 2,661 cm³ (162 cu inch (2.7 litre))correct |
| Bore | 3 7/16 inchescorrect |
| Stroke | 4 3/8 inchescorrect |
| Naturally aspirated | naturally aspiratedcorrect |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 3,175 mmcorrect |
|---|---|
| Length | 128 inches (3250 mm)correct |
| Width | 1,627 mmcorrect |
| Height | 1,854 mmcorrect |
| Unladen weight | 3, 700 lbs (1678 kg)correct |
Drivetrain and chassis
| Drive | rear-wheel drivecorrect |
|---|---|
| Gearbox | 5 V/1 Rcorrect |
| Gearbox make | M-Hcorrect |
| Forward gears | 5correct |
| Reverse gears | 1correct |
| Front tyres | 5.00 x 15correct |
| Rear tyres | 10.00 x 38correct |
| Top speed | 20 km/hcorrect |
Working data
| Fuel tank capacity | 86 l (20 gal (us))correct |
|---|
Origin and approval
| Plant | Racine, Wisconsin, USAcorrect |
|---|
Other data
| List price when new | $2, 065 (1952)correct |
|---|---|
| Predecessor | Massey-Harris 101 Juniorcorrect |
| Successor | Massey-Harris 33correct |
Frequently asked questions
What engine does the Massey Harris 30 have?
4 cylinders, 2,661 cm³ displacement, Gasoline G; Kerosene K.
How fast does the Massey Harris 30 go?
Top speed is 20 km/h.
What are the dimensions of the Massey Harris 30?
3,175 mm × 1,627 mm × 1,854 mm.
When was the Massey Harris 30 built?
Production years: 1946-1952.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 34 individual figures for this model. They come from 2 recorded sources; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
