Massey Ferguson MF8480
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The MF8480 is a tractor from the manufacturer Massey Ferguson. It belongs to the tractor series and was produced in the specified production period. The model is equipped with a six‑cylinder engine with a displacement of 8,419 cc and a rated power of 290 hp (213.4 kW) at 2,200 rpm. Its dimensions are 5,320 mm in length, 2,550 mm in width and 3,180 mm in height, with a wheelbase of 3,075 mm. The curb weight is 9,725 kg, it has a continuously variable transmission and a fuel tank capacity of 660 L. The tractor is classified in the lift‑category Cat III.
With 290 hp the MF8480 can handle heavy field tasks such as deep ploughing, mulching or pulling large implements. The large displacement and six cylinders provide high torque, which is especially useful when starting heavy loads. The continuously variable transmission delivers smooth power without gear‑shift interruptions, improving soil work efficiency. The substantial curb weight of 9,725 kg reduces ground pressure, enhancing traction on soft ground. A 660‑L tank allows long operating periods without frequent refuelling, which is practical for extensive field operations.
The MF8480 is suited for jobs that require high pulling power and long operating times. Because of its size and power, it is typically used for large‑area arable farming, heavy soil preparation and transporting heavy loads. The combination of a strong engine, CVT and large fuel capacity makes it appropriate for demanding agricultural tasks.
Massey Ferguson – other models: the collective page of tractors outside the named ranges, from the MF 35 and 135 through the 1000, 2000 and 3000 series to the MF 1200 (compact) and the 8700 S, 5 to 313 kW, Perkins
This page gathers the Massey Ferguson tractors the register could not assign to a named range – from the classics of the 1950s and 1960s such as the MF 35 and MF 135 from Coventry to current compact tractors and big tractors. Massey Ferguson emerged in 1953 from the merger of Massey-Harris (Toronto) with Harry Ferguson's tractor company, whose three-point hydraulics with draft control became the world standard; since 1994 the brand has belonged to AGCO, which builds the tractors in Beauvais, France, and sources the compact class from Iseki in Japan. The brand's type logic changed several times: the three-digit types 130 to 1200 of the 1960s and 1970s order the size in ascending order, the four-digit 1000 to 8000 series of the 1980s to 2000s give the range in the thousands digit and the model in the remaining digits (MF 1250 as compact, MF 3060 as mid-range), and since 2005 two digits mark the range and the last two the power step – MF 5710 as a 5700 with about 100 hp, MF 8737 as an 8700 with about 370 hp; S and the suffix Dyna-VT denote equipment and stepless transmission. The engines come from Perkins (the AD3.152 and 1104 series), AGCO Power (formerly Sisu) in the big and Iseki, Simpson (India) and Kohler in the small models.
Read on 3 more paragraphs
The register lists here 1,011 versions with 5.2 to 313 kW from one- to eight-cylinders of 1,123 to 8,419 cm³, PTO outputs from 19 to 290 hp, lift capacities from 540 to 9,950 kg, unladen weights from 670 to 12,000 kg, lengths from 2,480 to 6,200 mm and widths from 1,003 to 3,000 mm.
By unit numbers Massey Ferguson is one of the world's best-selling tractor brands, with strongholds in Britain, France, Scandinavia, Africa and South Asia, where the MF 240 and its Indian and Pakistani licence builds shape the market.
Used, the span is as wide as the brand: on classics originality and Perkins parts count, on compacts hydrostat and front loader, on the 5700 to 8700 operating hours, Dyna transmissions, electronics and exhaust aftertreatment; parts run through AGCO and Perkins.
Sources: SpecCodex register, model data: Massey Ferguson (weitere Modelle), Massey Ferguson (AGCO, Hersteller)
Technical data
Engine
| Power | 290 hp (213.4 kW)correct |
|---|---|
| Rated speed | 2,200 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 8,419 cm³correct |
Dimensions and weights
| Length | 5,320 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Height | 3,180 mmcorrect |
| Wheelbase | 3,075 mmcorrect |
| Unladen weight | 9,725 kgcorrect |
Drivetrain and chassis
| Gearbox | continuously variablecorrect |
|---|
Working data
| Fuel tank capacity | 660 lcorrect |
|---|
Other data
| Linkage category | Cat IIIcorrect |
|---|
Where this model stands
Power-to-weight ratio: 21.9 kW/t (213 kW / 9.7 t)
Power class: Heavy (> 180 hp)
Stronger than 97% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Massey Ferguson MF8480 have?
The Massey Ferguson MF8480 delivers 290 hp.
How much does the Massey Ferguson MF8480 weigh?
The unladen weight is 9,725 kg.
What engine does the Massey Ferguson MF8480 have?
6 cylinders, 8,419 cm³ displacement.
What are the dimensions of the Massey Ferguson MF8480?
5,320 mm × 2,550 mm × 3,180 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 13 individual figures for this model. They come from 2 recorded sources; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
