Massey Ferguson 6120
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Massey Ferguson 6120 belongs to the Massey Ferguson tractor family and is a medium‑size agricultural tractor. It is equipped with a four‑cylinder diesel engine with a displacement of 4 078 cm³ that delivers 80 hp (58,9 kW) at a rated speed of 2 200 rpm. The maximum torque of 285 Nm provides strong pulling power and the ability to start heavy implements easily. The transmission offers 16 forward and 16 reverse gears, allowing fine adjustment of travel speed to match field conditions. The fuel tank holds 130 l, enabling long periods of operation without frequent refuelling. Width of 1 850 mm, height of 2 654 mm and a Cat II lift category define the range of implements and transport tasks it can handle.
In use, the 80‑hp output means the tractor can comfortably pull medium to heavy implements such as ploughs, harrows or sprayers without a major loss of speed. The high torque is beneficial in heavy soils where strong start‑up force is required. Sixteen gear steps forward and backward provide a smooth range from very low speeds for precise field work to higher speeds for transport duties. The large fuel capacity reduces downtime, which is advantageous during extended field operations.
The Massey Ferguson 6120 is suited for typical tasks of a medium‑class tractor. It is appropriate for pulling medium‑sized implements, transporting loads on the farm and performing field work where a balanced combination of power, torque and gear range is needed. Its size and design make it a practical choice for farms that require efficient equipment for both field and yard operations.
Massey Ferguson – other models: the collective page of tractors outside the named ranges, from the MF 35 and 135 through the 1000, 2000 and 3000 series to the MF 1200 (compact) and the 8700 S, 5 to 313 kW, Perkins
This page gathers the Massey Ferguson tractors the register could not assign to a named range – from the classics of the 1950s and 1960s such as the MF 35 and MF 135 from Coventry to current compact tractors and big tractors. Massey Ferguson emerged in 1953 from the merger of Massey-Harris (Toronto) with Harry Ferguson's tractor company, whose three-point hydraulics with draft control became the world standard; since 1994 the brand has belonged to AGCO, which builds the tractors in Beauvais, France, and sources the compact class from Iseki in Japan. The brand's type logic changed several times: the three-digit types 130 to 1200 of the 1960s and 1970s order the size in ascending order, the four-digit 1000 to 8000 series of the 1980s to 2000s give the range in the thousands digit and the model in the remaining digits (MF 1250 as compact, MF 3060 as mid-range), and since 2005 two digits mark the range and the last two the power step – MF 5710 as a 5700 with about 100 hp, MF 8737 as an 8700 with about 370 hp; S and the suffix Dyna-VT denote equipment and stepless transmission. The engines come from Perkins (the AD3.152 and 1104 series), AGCO Power (formerly Sisu) in the big and Iseki, Simpson (India) and Kohler in the small models.
Read on 3 more paragraphs
The register lists here 1,011 versions with 5.2 to 313 kW from one- to eight-cylinders of 1,123 to 8,419 cm³, PTO outputs from 19 to 290 hp, lift capacities from 540 to 9,950 kg, unladen weights from 670 to 12,000 kg, lengths from 2,480 to 6,200 mm and widths from 1,003 to 3,000 mm.
By unit numbers Massey Ferguson is one of the world's best-selling tractor brands, with strongholds in Britain, France, Scandinavia, Africa and South Asia, where the MF 240 and its Indian and Pakistani licence builds shape the market.
Used, the span is as wide as the brand: on classics originality and Perkins parts count, on compacts hydrostat and front loader, on the 5700 to 8700 operating hours, Dyna transmissions, electronics and exhaust aftertreatment; parts run through AGCO and Perkins.
Sources: SpecCodex register, model data: Massey Ferguson (weitere Modelle), Massey Ferguson (AGCO, Hersteller)
Technical data
Engine
| Power | 80 hp (58.9 kW)correct |
|---|---|
| Rated speed | 2,200 rpmcorrect |
| Torque | 285 Nmcorrect |
| Cylinders | 4correct |
| Displacement | 4,078 cm³correct |
Dimensions and weights
| Width | 1,850 mmcorrect |
|---|---|
| Height | 2,654 mmcorrect |
Drivetrain and chassis
| Gearbox | 16V/16Rcorrect |
|---|---|
| Forward gears | 16correct |
| Reverse gears | 16correct |
Working data
| Fuel tank capacity | 130 lcorrect |
|---|
Other data
| Linkage category | Cat IIcorrect |
|---|---|
| PTO speed | 540/1000 rpmcorrect |
Frequently asked questions
How much power does the Massey Ferguson 6120 have?
The Massey Ferguson 6120 delivers 80 hp.
What engine does the Massey Ferguson 6120 have?
4 cylinders, 4,078 cm³ displacement.
What are the dimensions of the Massey Ferguson 6120?
1,850 mm × 2,654 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
