Massey Ferguson 3690
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Massey Ferguson 3690 is a tractor from the manufacturer, placed in the 190‑hp class. It is powered by a 6‑cylinder engine with a displacement of 7,365 cm³, reaching its peak output of 190 hp (139.8 kW) at a rated speed of 2,200 U/min. Dimensions are 5,165 mm in length, 2,391 mm in width and 2,905 mm in height, and the curb weight is 6,720 kg. Transmission options include 16V/16R or 32V/32R, the fuel tank holds 260 l, and the lift capacity falls into Cat II/III. Pump speeds are 540 U/min and 1,000 U/min.
A power rating of 190 hp enables the tractor to pull heavy implements and handle demanding field tasks, while the relatively low rated speed provides high torque at low engine speeds, beneficial for deep‑soil work. The curb weight of 6,720 kg results in moderate ground pressure, which is advantageous on sensitive soils. The large 260 l tank reduces refuelling stops during long operations, and the choice between 16‑ and 32‑gear gearboxes allows fine adjustment of travel speed to match various working conditions.
Given its size and specifications, the 3690 is suited for large‑area field work, heavy pulling tasks and transport of substantial loads. It is typically employed for intensive soil cultivation, seed distribution and harvest support where high drawbar pull and extended operating periods are required.
Massey Ferguson – other models: the collective page of tractors outside the named ranges, from the MF 35 and 135 through the 1000, 2000 and 3000 series to the MF 1200 (compact) and the 8700 S, 5 to 313 kW, Perkins
This page gathers the Massey Ferguson tractors the register could not assign to a named range – from the classics of the 1950s and 1960s such as the MF 35 and MF 135 from Coventry to current compact tractors and big tractors. Massey Ferguson emerged in 1953 from the merger of Massey-Harris (Toronto) with Harry Ferguson's tractor company, whose three-point hydraulics with draft control became the world standard; since 1994 the brand has belonged to AGCO, which builds the tractors in Beauvais, France, and sources the compact class from Iseki in Japan. The brand's type logic changed several times: the three-digit types 130 to 1200 of the 1960s and 1970s order the size in ascending order, the four-digit 1000 to 8000 series of the 1980s to 2000s give the range in the thousands digit and the model in the remaining digits (MF 1250 as compact, MF 3060 as mid-range), and since 2005 two digits mark the range and the last two the power step – MF 5710 as a 5700 with about 100 hp, MF 8737 as an 8700 with about 370 hp; S and the suffix Dyna-VT denote equipment and stepless transmission. The engines come from Perkins (the AD3.152 and 1104 series), AGCO Power (formerly Sisu) in the big and Iseki, Simpson (India) and Kohler in the small models.
Read on 3 more paragraphs
The register lists here 1,011 versions with 5.2 to 313 kW from one- to eight-cylinders of 1,123 to 8,419 cm³, PTO outputs from 19 to 290 hp, lift capacities from 540 to 9,950 kg, unladen weights from 670 to 12,000 kg, lengths from 2,480 to 6,200 mm and widths from 1,003 to 3,000 mm.
By unit numbers Massey Ferguson is one of the world's best-selling tractor brands, with strongholds in Britain, France, Scandinavia, Africa and South Asia, where the MF 240 and its Indian and Pakistani licence builds shape the market.
Used, the span is as wide as the brand: on classics originality and Perkins parts count, on compacts hydrostat and front loader, on the 5700 to 8700 operating hours, Dyna transmissions, electronics and exhaust aftertreatment; parts run through AGCO and Perkins.
Sources: SpecCodex register, model data: Massey Ferguson (weitere Modelle), Massey Ferguson (AGCO, Hersteller)
Technical data
Engine
| Power | 190 hp (139.8 kW)correct |
|---|---|
| Rated speed | 2,200 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 7,365 cm³correct |
Dimensions and weights
| Length | 5,165 mmcorrect |
|---|---|
| Width | 2,391 mmcorrect |
| Height | 2,905 mmcorrect |
| Unladen weight | 6,720 kgcorrect |
Drivetrain and chassis
| Gearbox | 16V/16R or 32V/32Rcorrect |
|---|
Working data
| Fuel tank capacity | 260 lcorrect |
|---|
Other data
| Linkage category | Cat II/IIIcorrect |
|---|---|
| PTO speed | 540/1000 rpmcorrect |
Where this model stands
Power-to-weight ratio: 20.8 kW/t (140 kW / 6.7 t)
Power class: Heavy (> 180 hp)
Stronger than 90% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Massey Ferguson 3690 have?
The Massey Ferguson 3690 delivers 190 hp.
How much does the Massey Ferguson 3690 weigh?
The unladen weight is 6,720 kg.
What engine does the Massey Ferguson 3690 have?
6 cylinders, 7,365 cm³ displacement.
What are the dimensions of the Massey Ferguson 3690?
5,165 mm × 2,391 mm × 2,905 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
