Massey Ferguson 175
Series: Other models
The Massey Ferguson 175 is a four-cylinder tractor of English manufacture, built from 1965 in Coventry and in a later S version until 1975. It was one of the models with which Massey Ferguson won the market in red and grey, and it carries a Perkins diesel engine.
The engine displaces 3,867 cm³ and delivers 66 PS (48.6 kW) at a rated speed of only 2,000 rpm. The low speed with large displacement stands for smooth running, long life and good pull from low revs. The gearbox with 12 forward and 4 reverse gears (12V/4R) covers mowing, ploughing and transport, and the top speed is 25 km/h. The tank holds 82 l and the Category I/II linkage takes the usual implements. At 3,470 mm long, 1,840 mm wide, 1,650 mm high, with a 2,134 mm wheelbase and 2,495 kg unladen weight, the 175 is compact and agile in the yard.
In the Massey Ferguson range the 175 was one of the stronger models of the line and worked on mixed farms at ploughing, grain-cart haulage and yard work. In Europe it was supplied with a diesel engine as standard.
Massey Ferguson – other models: the collective page of tractors outside the named ranges, from the MF 35 and 135 through the 1000, 2000 and 3000 series to the MF 1200 (compact) and the 8700 S, 5 to 313 kW, Perkins
This page gathers the Massey Ferguson tractors the register could not assign to a named range – from the classics of the 1950s and 1960s such as the MF 35 and MF 135 from Coventry to current compact tractors and big tractors. Massey Ferguson emerged in 1953 from the merger of Massey-Harris (Toronto) with Harry Ferguson's tractor company, whose three-point hydraulics with draft control became the world standard; since 1994 the brand has belonged to AGCO, which builds the tractors in Beauvais, France, and sources the compact class from Iseki in Japan. The brand's type logic changed several times: the three-digit types 130 to 1200 of the 1960s and 1970s order the size in ascending order, the four-digit 1000 to 8000 series of the 1980s to 2000s give the range in the thousands digit and the model in the remaining digits (MF 1250 as compact, MF 3060 as mid-range), and since 2005 two digits mark the range and the last two the power step – MF 5710 as a 5700 with about 100 hp, MF 8737 as an 8700 with about 370 hp; S and the suffix Dyna-VT denote equipment and stepless transmission. The engines come from Perkins (the AD3.152 and 1104 series), AGCO Power (formerly Sisu) in the big and Iseki, Simpson (India) and Kohler in the small models.
Read on 3 more paragraphs
The register lists here 1,011 versions with 5.2 to 313 kW from one- to eight-cylinders of 1,123 to 8,419 cm³, PTO outputs from 19 to 290 hp, lift capacities from 540 to 9,950 kg, unladen weights from 670 to 12,000 kg, lengths from 2,480 to 6,200 mm and widths from 1,003 to 3,000 mm.
By unit numbers Massey Ferguson is one of the world's best-selling tractor brands, with strongholds in Britain, France, Scandinavia, Africa and South Asia, where the MF 240 and its Indian and Pakistani licence builds shape the market.
Used, the span is as wide as the brand: on classics originality and Perkins parts count, on compacts hydrostat and front loader, on the 5700 to 8700 operating hours, Dyna transmissions, electronics and exhaust aftertreatment; parts run through AGCO and Perkins.
Sources: SpecCodex register, model data: Massey Ferguson (weitere Modelle), Massey Ferguson (AGCO, Hersteller)
Technical data
Engine
| Power | 66 hp (48.6 kW)correct |
|---|---|
| Rated speed | 2,000 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 3,867 cm³correct |
Dimensions and weights
| Length | 3,470 mmcorrect |
|---|---|
| Width | 1,840 mmcorrect |
| Height | 1,650 mmcorrect |
| Wheelbase | 2,134 mmcorrect |
| Unladen weight | 2,495 kgcorrect |
Drivetrain and chassis
| Gearbox | 12V/4Rcorrect |
|---|---|
| Forward gears | 12correct |
| Reverse gears | 4correct |
| Top speed | 25 km/hcorrect |
Working data
| Fuel tank capacity | 82 lcorrect |
|---|
Other data
| Linkage category | Cat I/IIcorrect |
|---|
Where this model stands
Power-to-weight ratio: 19.5 kW/t (49 kW / 2.5 t)
Power class: Universal (40–100 hp)
Stronger than 46% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Massey Ferguson 175 have?
The Massey Ferguson 175 delivers 66 hp.
How much does the Massey Ferguson 175 weigh?
The unladen weight is 2,495 kg.
What engine does the Massey Ferguson 175 have?
4 cylinders, 3,867 cm³ displacement.
How fast does the Massey Ferguson 175 go?
Top speed is 25 km/h.
What are the dimensions of the Massey Ferguson 175?
3,470 mm × 1,840 mm × 1,650 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 16 individual figures for this model. They come from 4 recorded sources; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
