Manitou 80XEL – specifications

The Manitou 80XEL is an electrically driven aerial work platform from the category of boom lifts, designed for use indoors and on sensitive surfaces. As a compact lift, this model targets users who need to perform precise work at height in enclosed halls or on smooth floors. The design omits an internal combustion engine in favor of an electric drive, ensuring zero emissions and low noise levels during operation.

The technical specifications highlight its suitability for indoor applications. With a width of 1,200 mm and a length of 2,800 mm, the machine can be maneuvered through narrow aisles, while a turning radius of 2,750 mm supports agility in confined spaces. The 16.5x11.25 solid tires are non-marking to prevent floor staining. The platform offers a load capacity of 570 kg and features a 1,200.1 mm extension for additional reach. The lift time of 40 s and the lowering time of 54 s define the rhythm of vertical movement, while the maximum speed of 3.5 km/h is designed for safe travel in work mode.

Power is supplied by a 24 V onboard voltage system with a battery capacity of 310 Ah, which determines the operating time between charges. A ground clearance of 120.1 mm allows the machine to traverse minor unevenness without compromising platform stability. The empty weight of 2,280 kg ensures sufficient stability when the platform is extended, without exceeding the load limits of many floors. This combination of low weight, electric drive, and specific dimensions positions the 80XEL as a specialized tool for maintenance, installation, and repair work in enclosed environments.
