MAN 8.145 FL/335
Built: 2002 · Series: 8.145
More machines from model year 2002
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The 2002 MAN 8.145 FL/335 is a very short distribution chassis: the wheelbase of 335 centimetres is the smallest in this selection, and the overall length is 6,800 mm. The width of 2,550 mm matches the maximum for box bodies, the kerb weight is 4,700 kg and the permissible gross weight 8,600 kg. The four-cylinder diesel of 4,580 cm³ delivers 103 kW.
The short wheelbase eases turning in narrow backyards and old-town lanes and gives the vehicle a small turning circle. Thanks to the low own weight a high payload remains, which can be put to good use for pallets and cartons in food and beverage retail.
The FL in the type code stands for the cab-over version with a light cab. In this design the driver sits above the engine, which keeps the vehicle length short. Used vehicles of this type are often sought by trade and delivery firms for which manoeuvrability matters more than long range.
MAN 8.145 – light chassis of the L2000 series: 8-tonne class with a 145 hp four-cylinder, cab codes F, FL, LC and LLC, gross-weight variants from 7.49 to 8.6 tonnes
The MAN 8.145 belongs to the L2000 series, introduced by MAN in the 1990s as the light and medium chassis class. In the type designation the first number gives the gross-weight class in tonnes and the second the engine output in horsepower, here 8 tonnes and 145 hp. The cab codes F and FL denote the long-haul and extended-nose cabs, LC and LLC chassis with a lower cab and lowered frame; the additional numbers after the hyphen, such as LC-7.5, give differing gross-weight variants of the same chassis in tonnes, and the number after the slash the wheelbase in centimetres.
Read on 3 more paragraphs
The register lists 11 versions with 103 kW from four-cylinder engines of 4,580 cc. Kerb weights range from 4,000 to 6,800 kg, gross vehicle weights from 7,490 to 8,600 kg. Lengths run from 5,300 to 7,920 mm, widths from 2,300 to 2,600 mm.
In the 7.5- to 8.6-tonne class, the 8.145 competed with the Mercedes-Benz 814/815 and the Iveco Cargo 75E; the chassis served as a common base for box, drop-side and refrigerated bodies in urban distribution transport.
On a used example, checks should cover corrosion on the frame and spring brackets, the condition of the clutch and five-speed gearbox, sealing of the turbocharger on the four-cylinder engine, and brakes and wheel bearings from frequent urban stop-and-go use; spare parts run through the MAN service network.
Sources: SpecCodex register, model data: MAN 8.145, MAN (manufacturer)
Technical data
Engine
| Power | 103 kWcorrect |
|---|---|
| Displacement | 4,580 cm³correct |
Dimensions and weights
| Length | 6,800 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Unladen weight | 4,700 kgcorrect |
| Gross vehicle weight | 8,600 kgcorrect |
Where this model stands
Power-to-weight ratio: 21.9 kW/t (103 kW / 4.7 t)
Stronger than 7% of the trucks in the register — out of 25,242 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the MAN 8.145 FL/335 have?
The MAN 8.145 FL/335 delivers 103 kW.
How much does the MAN 8.145 FL/335 weigh?
The unladen weight is 4,700 kg.
What is the gross vehicle weight of the MAN 8.145 FL/335?
8,600 kg.
What engine does the MAN 8.145 FL/335 have?
4,580 cm³ displacement.
What are the dimensions of the MAN 8.145 FL/335?
6,800 mm × 2,550 mm.
When was the MAN 8.145 FL/335 built?
Production years: 2002.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 7 individual figures for this model. They come from 2 recorded sources; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
