MAN 10.224 FL/300 – specifications
Built: 2000 · Series: 10.224
The 10.224 FL/300 from MAN is part of the 10224 series. Production: 2000. The engine delivers 162 kW, with a displacement of 6,870 cm³. The vehicle is 6,050 mm long and 2,300 mm wide. The unladen weight is 7,000 kg. The gross vehicle weight is 10,500 kg. The 10.224 series covers 9 models. Rated output within it ranges from 162 to 165 kW; the 10.224 FL/300 sits at the bottom of that range with 162 kW. Its immediate neighbours are the 10.224 LAEC-356-4X4/386 above it with 165 kW. Unladen weight within it ranges from 4,300 to 7,900 kg; here the 10.224 FL/300 sits in the upper part of that range with 7,000 kg. 5237 MAN models across 68 series are on record.
Data for the version built 2000 · Data origin: Official register · sources
More machines from model year 2000
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
MAN 10.224 – trucks of the 10-tonne class: inline six-cylinder with 162 to 165 kW, all-wheel-drive LAEC special versions, gross weights from 10,000 to 10,500 kg, 9 versions in the register
MAN of Munich, in its truck ranges of the 1980s and 1990s, follows a type logic in which the first number gives the weight class in tonnes and the number after the point gives the engine output in hp: 10.224 thus denotes a 10-tonne-class truck with about 224 hp. The cab suffixes F and FL mark cab variants, LLC a further cab version; the models with the LAEC suffix are all-wheel-drive special versions for off-road use.
Read on 3 more paragraphs
The register lists nine versions with 162 to 165 kW from the 6.9-litre six-cylinder, unladen weights from 4,300 to 7,900 kg, gross weights from 10,000 to 10,500 kg, lengths from 5,900 to 8,250 mm and widths from 2,200 to 2,600 mm.
The 10-tonne class occupies the transition from light to medium-heavy truck at MAN and was bodied both as a dropside in distribution traffic and, in the all-wheel-drive LAEC versions, as an off-road chassis for fire brigades, recovery and military use, where above all the ability to cope with rough terrain counts.
On used examples, operating hours and the condition of the injection pump matter, along with clutch and gearbox, on the all-wheel-drive versions the transfer case and axles, rust on the frame and cab, and the condition of brakes and suspension; parts run through the MAN network, though partly limited on the special LAEC versions.
Sources: SpecCodex register, model data: MAN 10.224, MAN Truck & Bus (manufacturer)
Technical data
Engine
| Power | 162 kWcorrect |
|---|---|
| Displacement | 6,870 cm³correct |
Dimensions and weights
| Length | 6,050 mmcorrect |
|---|---|
| Width | 2,300 mmcorrect |
| Unladen weight | 7,000 kgcorrect |
| Gross vehicle weight | 10,500 kgcorrect |
Frequently asked questions
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 7 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Are you the manufacturer or a dealer of this machine? Check the data and add missing figures — we mark your correction as manufacturer or dealer information.
Check and complete the data →Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
