MAN 10.223 FL
Built: 1994-1994 · Series: 10.223
More machines from model year 1994
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
MAN 10.223 – 10-tonne class truck with a 223hp engine: 6,870cc six-cylinder, F and FL cabs, LAEC-4X4 all-wheel-drive version, unladen weight 4.75 to 7.8 tonnes
In MAN's type numbering the first figure marks the gross-vehicle-weight class in tonnes and the second the engine output in horsepower; the 10.223 thus denotes the 10-tonne class with about 223hp, matching the measured output here of 161.5 to 164kW. F and FL mark the forward-control cab variants, LAEC-4X4 the off-road all-wheel-drive version, and the suffixes from /300 to /460 distinguish chassis with different wheelbases. MAN was formed in 1908 from the merger of Maschinenfabrik Augsburg with the Nuremberg-based Maschinenbau-Actien-Gesellschaft, building light and medium trucks of this generation in parallel under the L2000 and M2000 names.
Read on 3 more paragraphs
The register lists 9 versions with 161.5 to 164kW, a displacement of 6,870cc, unladen weights from 4,750 to 7,800kg, gross vehicle weights from 10,000 to 10,500kg, lengths from 5,350 to 8,320mm and widths from 2,300 to 2,600mm.
In the 10-tonne class the 10.223 covered distribution work, tipper and construction-site duty, and – in the all-wheel-drive version – municipal and farm-adjacent off-road use; it competed against the Mercedes 1017/1019-class trucks.
Buying used, check the frame and axle mounts for rust on the longer-wheelbase chassis, the condition of the clutch and gearbox, on 4X4 versions the transfer case and differential locks, the brakes, and – depending on the body – the tipper hydraulics or tail-lift; spare parts run through the MAN network. The condition of the tow hitch on the longer-wheelbase chassis and the tightness of the cab mounts are also worth checking.
Technical data
Engine
| Displacement | 6,870 cm³correct |
|---|
Dimensions and weights
| Length | 5,750 mmcorrect |
|---|---|
| Width | 2,300 mmcorrect |
| Unladen weight | 4,750 kgcorrect |
| Gross vehicle weight | 10,500 kgcorrect |
Frequently asked questions
How much does the MAN 10.223 FL weigh?
The unladen weight is 4,750 kg.
What is the gross vehicle weight of the MAN 10.223 FL?
10,500 kg.
What engine does the MAN 10.223 FL have?
6,870 cm³ displacement.
What are the dimensions of the MAN 10.223 FL?
5,750 mm × 2,300 mm.
When was the MAN 10.223 FL built?
Production years: 1994.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 6 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
