Link-Belt 290LX

Series: Link-Belt Log Loader

Source: https://www.lectura-specs.com/en/model/construction-machiner

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The 290LX from Link-Belt is part of the Link-Belt Log Loader series. The engine delivers 132 kW, has 6 cylinders, with a displacement of 6,489.3 cm³. Rated speed is 2,200 rpm. The unladen weight is 36,016.1 kg. Ground clearance is 707.1 mm. Top speed is 4 km/h. The tank holds 340.3 litres. Maximum torque is reached at 1,800 rpm. The pump delivers 442.1 l/min. The hydraulic tank holds 240.4 litres. Working pressure is 342.7 bar. The cooling system holds 29.1 litres. The oil fill is 24.2 litres. The electrical system runs on 24 V. The engine fitted is the CC-6BG1TC. The Link-Belt Log Loader series covers 4 models. Rated output within it ranges from 102.9 to 184.2 kW; the 290LX sits in the lower part of that range with 132 kW. Its immediate neighbours are the 240LX below it with 120.8 kW and the 370LX above it with 184.2 kW. 157 Link-Belt models across 10 series are on record. The model is listed under Excavators & compaction. 18 verified figures from 1 source are on file.

Technical data

Engine

Engine modelCC-6BG1TCcorrect
Power132 kWcorrect
Rated speed2,200 rpmcorrect
Speed at max. torque1,800 rpmcorrect
Cylinders6correct
Displacement6,489.3 cm³correct
AspirationTurbocharged with Intercoolercorrect
Coolant capacity29.1 lcorrect
Engine oil capacity24.2 lcorrect

Dimensions and weights

Width3,642.4correct
Ground clearance707.1correct
Unladen weight36,016.1 kgcorrect

Drivetrain and chassis

Top speed4 km/hcorrect
System voltage24 Vcorrect

Working data

Pump flow442.1 l/mincorrect
Hydraulic oil capacity240.4 lcorrect
Hydraulic pressure342.7correct
Fuel tank capacity340.3 lcorrect

Where this model stands

Power-to-weight ratio: 3.7 kW/t (132 kW / 36 t)

Stronger than 64% of the excavators & compaction in the register — out of 1,666 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Link-Belt 290LX have?

The Link-Belt 290LX delivers 132 kW.

How much does the Link-Belt 290LX weigh?

The unladen weight is 36,016 kg.

What engine does the Link-Belt 290LX have?

6 cylinders, 6,489 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
