Link-Belt 240LX

Series: Link-Belt Log Loader

Source: https://www.lectura-specs.fr/fr/modele/machines-de-chantier/

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Link-Belt 240LX is a model in the Link-Belt Log Loader series. The engine delivers 120.8 kW, has 6 cylinders, with a displacement of 6,489.3 cm³. Rated speed is 2,150 rpm. The unladen weight is 33,926 kg. Ground clearance is 707.1 mm. Top speed is 4.8 km/h. The tank holds 340.3 litres. Maximum torque is reached at 1,800 rpm. The pump delivers 424 l/min. The hydraulic tank holds 225.2 litres. Working pressure is 342.7 bar. The cooling system holds 27.3 litres. The oil fill is 24.2 litres. The electrical system runs on 24 V. The engine fitted is the BB-6BG1T. The Link-Belt Log Loader series covers 4 models. Rated output within it ranges from 102.9 to 184.2 kW; the 240LX sits in the lower part of that range with 120.8 kW. Its immediate neighbours are the 210LX below it with 102.9 kW and the 290LX above it with 132 kW. 157 Link-Belt models across 10 series are on record. The model is listed under Excavators & compaction. 18 verified figures from 1 source are on file.

Technical data

Engine

Engine modelBB-6BG1Tcorrect
Power120.8 kWcorrect
Rated speed2,150 rpmcorrect
Speed at max. torque1,800 rpmcorrect
Cylinders6correct
Displacement6,489.3 cm³correct
Aspirationturbochargedcorrect
Coolant capacity27.3 lcorrect
Engine oil capacity24.2 lcorrect

Dimensions and weights

Width3,645.4correct
Ground clearance707.1correct
Unladen weight33,926 kgcorrect

Drivetrain and chassis

Top speed4.8 km/hcorrect
System voltage24 Vcorrect

Working data

Pump flow424 l/mincorrect
Hydraulic oil capacity225.2 lcorrect
Hydraulic pressure342.7correct
Fuel tank capacity340.3 lcorrect

Where this model stands

Power-to-weight ratio: 3.6 kW/t (121 kW / 33.9 t)

Stronger than 57% of the excavators & compaction in the register — out of 1,666 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Link-Belt 240LX have?

The Link-Belt 240LX delivers 121 kW.

How much does the Link-Belt 240LX weigh?

The unladen weight is 33,926 kg.

What engine does the Link-Belt 240LX have?

6 cylinders, 6,489 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
