Link-Belt 210LX

Series: Link-Belt Log Loader

Source: https://www.lectura-specs.com/en/model/construction-machiner

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Link-Belt 210LX is a model in the Link-Belt Log Loader series. The engine delivers 102.9 kW, has 6 cylinders, with a displacement of 6,489.3 cm³. Rated speed is 1,950 rpm. The unladen weight is 26,767.8 kg. Ground clearance is 701 mm. Top speed is 3.3 km/h. The tank holds 340.3 litres. Maximum torque is reached at 1,600 rpm. The pump delivers 402 l/min. The hydraulic tank holds 206.3 litres. Working pressure is 342.7 bar. The cooling system holds 27.3 litres. The oil fill is 24.2 litres. The electrical system runs on 24 V. The engine fitted is the BB-6BG1T. The Link-Belt Log Loader series covers 4 models. Rated output within it ranges from 102.9 to 184.2 kW; the 210LX sits at the bottom of that range with 102.9 kW. Its immediate neighbours are the 240LX above it with 120.8 kW. 157 Link-Belt models across 10 series are on record. The model is listed under Excavators & compaction. 18 verified figures from 1 source are on file.

Technical data

Engine

Engine modelBB-6BG1Tcorrect
Power102.9 kWcorrect
Rated speed1,950 rpmcorrect
Speed at max. torque1,600 rpmcorrect
Cylinders6correct
Displacement6,489.3 cm³correct
Aspirationturbochargedcorrect
Coolant capacity27.3 lcorrect
Engine oil capacity24.2 lcorrect

Dimensions and weights

Width3,645.4correct
Ground clearance701correct
Unladen weight26,767.8 kgcorrect

Drivetrain and chassis

Top speed3.3 km/hcorrect
System voltage24 Vcorrect

Working data

Pump flow402 l/mincorrect
Hydraulic oil capacity206.3 lcorrect
Hydraulic pressure342.7correct
Fuel tank capacity340.3 lcorrect

Where this model stands

Power-to-weight ratio: 3.8 kW/t (103 kW / 26.8 t)

Stronger than 42% of the excavators & compaction in the register — out of 1,666 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Link-Belt 210LX have?

The Link-Belt 210LX delivers 103 kW.

How much does the Link-Belt 210LX weigh?

The unladen weight is 26,768 kg.

What engine does the Link-Belt 210LX have?

6 cylinders, 6,489 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
