Link-Belt 240X2 Long Front – specifications
Series: Link-Belt Hydraulic Excavator
The Link-Belt 240X2 Long Front belongs to the Link-Belt Hydraulic Excavator series. The engine delivers 132 kW, has 4 cylinders, with a displacement of 5,201.3 cm³. Torque is 635.9 Nm. Rated speed is 2,000 rpm. The unladen weight is 27,999.8 kg. Ground clearance is 460.2 mm. The tank holds 410.3 litres. Maximum torque is reached at 1,500 rpm. The pump delivers 467.9 l/min. The hydraulic tank holds 250.2 litres. Working pressure is 342.7 bar. The cooling system holds 25.4 litres. The oil fill is 23.5 litres. The electrical system runs on 24 V. The engine fitted is the AH-4HK1X. The Link-Belt Hydraulic Excavator series covers 40 models. Rated output within it ranges from 63.4 to 331.1 kW; the 240X2 Long Front sits in the lower part of that range with 132 kW. Its immediate neighbours are the 240LX Road Builder below it with 120.8 kW and the 3900 Quantum above it with 132.7 kW. Unladen weight within it ranges from 12,292.4 to 80,013.7 kg; here the 240X2 Long Front sits in the lower part of that range with 27,999.8 kg. 157 Link-Belt models across 11 series are on record.
Build year not documented · Data origin: Directory data · sources
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Link-Belt Hydraulic Excavator: what LX, X2, X3 and X4 actually mean
The "Link-Belt Hydraulic Excavator" bucket on SpecCodex groups 40 live-listed models from one US crawler-excavator family, spanning compact to large machines. Reading a code like 130LX or 210X2 means separating two layers: the number before the suffix (130, 160, 210, 240…) names the size class, while the letters/digits after it name the production series.
Read on 4 more paragraphs
LX was the earlier series until LBX Company introduced the X2 generation in 2007: a re-engineered Tier III diesel with common-rail injection, a turbocharger with intercooler, more power at lower rpm, and a load-sensing hydraulic system delivering extra power boost under heavy work. X3 and X4 followed later within the same size scheme, which is why the bucket lists LX and X2 variants of the same base number side by side (e.g. 130LX next to 130X2).
The recorded range shows how wide the line-up is: engine output 63 to 331 kW, operating weight 12,292 to 80,013 kg, displacement 3,000 to 15,698 cm³ across 4- to 6-cylinder engines.
For a used machine, the generation on the nameplate matters more than the bare number: X2-era models feature cast boom- and arm-tip components and an Extended Maintenance System on pins and bushings for longer lube intervals — the service book shows whether that schedule was kept. On older LX machines, also check track tension, rollers, and the condition of hydraulic cylinders and the main pump.
In short: number = size class, suffix = generation. Since the bucket mixes both generations under one entry, only the nameplate or serial number gives a reliable answer.
Sources: SpecCodex register, model data: Link-Belt Hydraulic Excavator, — LBX Company: Firmengeschichte / Modellgenerationen, — Link-Belt Excavators: Prior Models Übersicht, — Equipment World: Link-Belt 130 X2 Series Ankündigung
Technical data
Engine
| Engine model | AH-4HK1Xcorrect |
|---|---|
| Power | 132 kWcorrect |
| Rated speed | 2,000 rpmcorrect |
| Torque | 635.9 Nmcorrect |
| Speed at max. torque | 1,500 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 5,201.3 cm³correct |
| Aspiration | turbochargedcorrect |
| Coolant capacity | 25.4 lcorrect |
| Engine oil capacity | 23.5 lcorrect |
Dimensions and weights
| Ground clearance | 460.2 mmcorrect |
|---|---|
| Unladen weight | 27,999.8 kgcorrect |
Working data
| Pump flow | 467.9 l/mincorrect |
|---|---|
| Hydraulic oil capacity | 250.2 lcorrect |
| Hydraulic pressure | 342.7 barcorrect |
| Fuel tank capacity | 410.3 lcorrect |
Other data
| Cab height | 3,002.3 mmcorrect |
|---|---|
| System voltage | 24 Vcorrect |
Frequently asked questions
More machines with this engine (AH-4HK1X, 6)
Where this model stands
Power-to-weight ratio: 4.7 kW/t (132 kW / 28 t)
Stronger than 65% of the excavators & compaction in the register — out of 1,650 models with a stated power figure.
Calculated from the documented figures above — not a rating.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
