Lamborghini R 583 (DT)
Built: 1982–1985 · Series: 583
More machines from model year 1982
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Lamborghini R 583 (DT) – air-cooled three-cylinder diesel producing 53 hp at 2,300 rpm from 2,827 cc, with four-wheel drive (doppia trazione), built 1982 to 1985, Lamborghini Trattori
Lamborghini Trattori began as an independent tractor works in Italy, founded by Ferruccio Lamborghini before his later fame as a sports car maker; the tractor business stayed independent of the car marque and has belonged to the SAME group (today SDF, SAME Deutz-Fahr) since the 1970s. The R 583 (DT) is an early-1980s four-wheel-drive tractor built for medium-heavy field work; Italian makers use DT for doppia trazione, meaning four-wheel drive.
Read on 3 more paragraphs
The R 583 (DT) is powered by an air-cooled three-cylinder diesel engine of 2,827 cc, producing 53 hp (39 kW) at 2,300 rpm with 169 Nm of torque. At a kerb weight of 1,970 kg it measures 3,300 mm in length, 1,600 mm in width and 2,200 mm in height, on a 2,004 mm wheelbase; top speed is 25 km/h.
An air-cooled three-cylinder of nearly 2.8 litres provides power enough for tillage, mowing and haulage on medium-sized areas. The comparatively high rated speed of 2,300 rpm means the engine develops its power in the upper speed range and needs regular attention to cooling and a clean air filter. Four-wheel drive markedly improves traction on grassland and soft ground compared with a two-wheel-drive version.
When buying a used air-cooled four-wheel-drive Lamborghini of this type, the cylinder cooling fins, the condition of the air filter and the tightness of the valve covers are among the first things to check. On the front axle and the four-wheel-drive joints, intensive field work first shows up as play and noise. Parts for engine and drivetrain are usually still available through dealers specialising in Italian tractors.
Sources: SpecCodex-Register: Kennwerte des Modells Lamborghini R 583 (DT)
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 53 hp (39 kW)correct |
| Rated speed | 2,300 rpmcorrect |
| Torque | 169 Nmcorrect |
| Speed at max. torque | 1,700 rpmcorrect |
| Cylinders | 3correct |
| Displacement | 2,827 cm³correct |
| Bore | 100 mmcorrect |
| Stroke | 120 mmcorrect |
| Compression ratio | 16.5correct |
| Injection pressure | 220 barcorrect |
| Cooling | air-cooledcorrect |
Dimensions and weights
| Length | 3,300 mmcorrect |
|---|---|
| Width | 1,600 mmcorrect |
| Height | 2,200 mmcorrect |
| Wheelbase | 2,004 mmcorrect |
| Ground clearance | 470 mmcorrect |
| Unladen weight | 1,970 kgcorrect |
Drivetrain and chassis
| Drive | rear- or four-wheel drivecorrect |
|---|---|
| Gearbox | 12 V/3 Rcorrect |
| Front tyres | 6.00-16 ASF (DT: 9.5-20 AS)correct |
| Rear tyres | 13.6-28 AScorrect |
| Top speed | 25 km/hcorrect |
Origin and approval
| Construction | unit construction (no separate frame)correct |
|---|
Where this model stands
Power-to-weight ratio: 19.8 kW/t (39 kW / 2 t)
Power class: Universal (40–100 hp)
Stronger than 37% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Lamborghini R 583 (DT) have?
The Lamborghini R 583 (DT) delivers 53 hp.
How much does the Lamborghini R 583 (DT) weigh?
The unladen weight is 1,970 kg.
What engine does the Lamborghini R 583 (DT) have?
3 cylinders, 2,827 cm³ displacement, Diesel.
How fast does the Lamborghini R 583 (DT) go?
Top speed is 25 km/h.
What are the dimensions of the Lamborghini R 583 (DT)?
3,300 mm × 1,600 mm × 2,200 mm.
When was the Lamborghini R 583 (DT) built?
Production years: 1982–1985.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
