Kultour SMART STAGE 80
Built: 2016 · Series: Other models
More machines from model year 2016
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Kultour – other models: the collective page of trailers outside the named ranges, SMART STAGE 20 and SMART STAGE 80, 1,640 to 19,600 kg unladen weight, 1,800 to 29,000 kg gross weight
This page gathers the Kultour trailers the register could not assign to a named range – with only two versions this amounts to the whole programme listed here. The types SMART STAGE 20 and SMART STAGE 80 carry the suffix Stage, pointing to mobile stage trailers, while the attached number distinguishes the two versions by size. As with many smaller trailer brands, the programme is drawn from registration data, in which each model is listed individually with its technical values.
Read on 3 more paragraphs
The register lists here 2 versions with unladen weights from 1,640 to 19,600 kg, gross weights from 1,800 to 29,000 kg, a length of 11,700 mm and widths from 2,350 to 2,520 mm.
The huge gap between the two versions – from a trailer of barely one and a half tonnes to one of almost 30 tonnes – shows how differently sized mobile stage and event structures can be, depending on whether a small act or a large open-air stage is being moved. Such trailers usually end up not with private owners but with event companies and hire firms.
On a used example at this size, the condition of axles and brakes, rust on frame and hydraulic lines, the function of the fold-out and lifting mechanism for the stage surface, the tightness of the floor covering, and lighting, tyres and rims all count. Parts for such a small model count usually run through independent trailer workshops or firms specialising in event technology. Before first use it is also worth checking stability and the support points with the stage deployed.
Sources: SpecCodex register, model data: Kultour (weitere Modelle)
Technical data
Dimensions and weights
| Length | 11,700 mmcorrect |
|---|---|
| Width | 2,520 mmcorrect |
| Wheelbase | 7,150 mmcorrect |
| Unladen weight | 19,600 kgcorrect |
| Gross vehicle weight | 29,000 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
How much does the Kultour SMART STAGE 80 weigh?
The unladen weight is 19,600 kg.
What is the gross vehicle weight of the Kultour SMART STAGE 80?
29,000 kg.
Up to what speed is the Kultour SMART STAGE 80 approved?
Approved up to 100 km/h.
What are the dimensions of the Kultour SMART STAGE 80?
11,700 mm × 2,520 mm.
When was the Kultour SMART STAGE 80 built?
Production years: 2016.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 8 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
Sources: RDW — Dutch national vehicle register (retrieved August 2026) · How we check the data
