Kubota R41 4WD
Series: Other models
As a tractor, the Kubota R41 belongs to the Kubota 4WD Tractor series. Under the bonnet works a four-cylinder engine displacing 1.8 litres, producing 42 hp (30.6 kW). Rated power is reached at 2,600 rpm.
Top speed is 30 km/h.
Within the range, rated power spans from 18.2 to 116 hp; with 41.6 hp, the R41 sits in the mid-field. Directly alongside are the L3940HSTC with 41.1 hp below and the U43 with 43.6 hp above.
Technical data
Engine
| Engine model | S4QScorrect |
|---|---|
| Power | 41.6 hp (30.6 kW)correct |
| Rated speed | 2,600 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 1,758.3 cm³correct |
Drivetrain and chassis
| Gearbox type | synchro shuttlecorrect |
|---|---|
| Forward gears | 16correct |
| Reverse gears | 12correct |
| Tyre size | 8-16, 4PRcorrect |
| Top speed | 30.3 km/hcorrect |
| System voltage | 12 Vcorrect |
Working data
| Hydraulic pressure | 170correct |
|---|---|
| Fuel tank capacity | 40.1 lcorrect |
Other data
| Height | 2,417.1correct |
|---|
Frequently asked questions
How much power does the Kubota R41 have?
The Kubota R41 delivers 41.6 hp.
What engine does the Kubota R41 have?
4 cylinders, 1,758 cm³ displacement.
How fast does the Kubota R41 go?
Top speed is 30.3 km/h.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 15 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
