Kubota M105SHDC 4WD
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Kubota M105SHDC is a tractor from the Kubota 4WD Tractor series. Power comes from a four-cylinder engine; from 3.8 litres it draws 78.3 kW. Rated speed is 2,600 rpm.
Unladen weight is 3,460 kg.
Within the range, rated power spans from 13.4 to 93.2 kW; with 78.3 kW, the M105SHDC sits at the top. Directly alongside are the M6S-111SDS with 77.9 kW below and the M108SDS with 80.5 kW above.
Technical data
Engine
| Engine model | V3800-DI-TIcorrect |
|---|---|
| Power | 78.3 kWcorrect |
| Rated speed | 2,600 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 3,769 cm³correct |
| Aspiration | turbocharged w/ intercoolercorrect |
Dimensions and weights
| Ground clearance | 435.1correct |
|---|---|
| Unladen weight | 3,460 kgcorrect |
Drivetrain and chassis
| Gearbox type | fully synchromesh gearboxcorrect |
|---|---|
| Forward gears | 16correct |
| Reverse gears | 16correct |
| Tyre size | front 13.6-24 rear 18.4-34correct |
Working data
| Pump flow | 65.1 l/mincorrect |
|---|---|
| Fuel tank capacity | 175.3 lcorrect |
Other data
| Height | 2,682.2correct |
|---|
Where this model stands
Power-to-weight ratio: 22.6 kW/t (78 kW / 3.5 t)
Power class: Large (100–180 hp)
Stronger than 71% of the tractors in the register — out of 15,240 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Kubota M105SHDC have?
The Kubota M105SHDC delivers 78.3 kW.
How much does the Kubota M105SHDC weigh?
The unladen weight is 3,460 kg.
What engine does the Kubota M105SHDC have?
4 cylinders, 3,769 cm³ displacement.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 15 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
