Kubota M105SHC 2WD
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
As a tractor, the Kubota M105SHC belongs to the Kubota 2WD Tractor series. Under the bonnet works a four-cylinder engine displacing 3.8 litres, producing 78.3 kW. Rated power is reached at 2,600 rpm.
It measures 2.01 m across. Unladen, it tips the scales at 3,200 kg.
Within the range, rated power spans from 17.8 to 89.5 kW; with 78.3 kW, the M105SHC sits in the upper third. Directly alongside are the M96SH with 70.8 kW below and the M108SDSF with 80.5 kW above.
Technical data
Engine
| Engine model | V3800-DI-TIcorrect |
|---|---|
| Power | 78.3 kWcorrect |
| Rated speed | 2,600 rpmcorrect |
| Cylinders | 4correct |
| Displacement | 3,769 cm³correct |
| Aspiration | turbocharged w/ intercoolercorrect |
Dimensions and weights
| Width | 2,011.7correct |
|---|---|
| Wheelbase | 2,435.4correct |
| Ground clearance | 435.1correct |
| Unladen weight | 3,200 kgcorrect |
Drivetrain and chassis
| Gearbox type | fully synchromesh gearboxcorrect |
|---|---|
| Forward gears | 16correct |
| Reverse gears | 16correct |
Working data
| Pump flow | 65.1 l/mincorrect |
|---|---|
| Fuel tank capacity | 175.3 lcorrect |
Where this model stands
Power-to-weight ratio: 24.5 kW/t (78 kW / 3.2 t)
Power class: Large (100–180 hp)
Stronger than 71% of the tractors in the register — out of 15,240 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Kubota M105SHC have?
The Kubota M105SHC delivers 78.3 kW.
How much does the Kubota M105SHC weigh?
The unladen weight is 3,200 kg.
What engine does the Kubota M105SHC have?
4 cylinders, 3,769 cm³ displacement.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 15 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
