Kubota L4760HSTCC MFWD
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Kubota L4760HSTCC is a tractor from the Kubota MFWD Tractor series. The four-cylinder engine, displacing 2.4 litres, produces 50 hp (35 kW).
Top speed is 27 km/h. It measures 3.09 m in length and 1.69 m in width. Unladen weight is 1,845 kg.
Within the range, rated power spans from 22.3 to 170 hp; with 49.7 hp, the L4760HSTCC sits in the mid-field. Directly alongside are the L4701-HST with 48 hp below and the L5060GSTRC with 52.7 hp above.
Technical data
Engine
| Engine make | KUBOTAcorrect |
|---|---|
| Engine model | L4760HSTCCcorrect |
| Power | 49.7 hp (35 kW)correct |
| Cylinders | 4correct |
| Displacement | 2,433.5 cm³correct |
| Aspiration | Natural with EGRcorrect |
Dimensions and weights
| Length | 3,085.1correct |
|---|---|
| Width | 1,691.6correct |
| Wheelbase | 1,895.9correct |
| Ground clearance | 360.2correct |
| Unladen weight | 1,845 kgcorrect |
Drivetrain and chassis
| Gearbox type | HST Pluscorrect |
|---|---|
| Forward gears | 6correct |
| Reverse gears | 6correct |
| Top speed | 27 km/hcorrect |
| Turning radius | 2,710 mmcorrect |
| System voltage | 12 Vcorrect |
Working data
| Lifting capacity | 1,250 kgcorrect |
|---|---|
| Pump flow | 17.8 l/mincorrect |
| Fuel tank capacity | 51.1 lcorrect |
| PTO output | 40 hpcorrect |
Where this model stands
Power-to-weight ratio: 19 kW/t (35 kW / 1.8 t)
Power class: Universal (40–100 hp)
Stronger than 33% of the tractors in the register — out of 14,914 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Kubota L4760HSTCC have?
The Kubota L4760HSTCC delivers 49.7 hp.
How much does the Kubota L4760HSTCC weigh?
The unladen weight is 1,845 kg.
What engine does the Kubota L4760HSTCC have?
4 cylinders, 2,434 cm³ displacement.
How fast does the Kubota L4760HSTCC go?
Top speed is 27 km/h.
What is the PTO output of the Kubota L4760HSTCC?
PTO output is 40 hp.
How much does the rear linkage of the Kubota L4760HSTCC lift?
The rear linkage lifts 1,250 kg.
What are the dimensions of the Kubota L4760HSTCC?
3,085 mm × 1,692 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 22 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
