Kubota L3560HSTCC MFWD
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Kubota L3560HSTCC is a tractor from the Kubota MFWD Tractor series. Power comes from a three-cylinder engine; from 2.4 litres it draws 38 hp (26.1 kW).
Top speed is 27 km/h. It measures 2.92 m in length and 1.52 m in width. Unladen weight is 1,745 kg.
Within the range, rated power spans from 22.3 to 170 hp; with 37.5 hp, the L3560HSTCC sits in the lower third. Directly alongside are the L3301-HST with 33.5 hp below and the L3901-HST with 38 hp above.
Technical data
Engine
| Engine make | KUBOTAcorrect |
|---|---|
| Engine model | L3560HSTCCcorrect |
| Power | 37.5 hp (26.1 kW)correct |
| Cylinders | 3correct |
| Displacement | 2,433.5 cm³correct |
| Aspiration | Natural with EGRcorrect |
Dimensions and weights
| Length | 2,920.2correct |
|---|---|
| Width | 1,521correct |
| Wheelbase | 1,807.5correct |
| Ground clearance | 342.1correct |
| Unladen weight | 1,745 kgcorrect |
Drivetrain and chassis
| Gearbox type | HST Pluscorrect |
|---|---|
| Forward gears | 6correct |
| Reverse gears | 6correct |
| Top speed | 26.6 km/hcorrect |
| System voltage | 12 Vcorrect |
Working data
| Pump flow | 17.8 l/mincorrect |
|---|---|
| Fuel tank capacity | 51.1 lcorrect |
Where this model stands
Power-to-weight ratio: 15 kW/t (26 kW / 1.7 t)
Power class: Compact (< 40 hp)
Stronger than 23% of the tractors in the register — out of 15,240 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Kubota L3560HSTCC have?
The Kubota L3560HSTCC delivers 37.5 hp.
How much does the Kubota L3560HSTCC weigh?
The unladen weight is 1,745 kg.
What engine does the Kubota L3560HSTCC have?
3 cylinders, 2,434 cm³ displacement.
How fast does the Kubota L3560HSTCC go?
Top speed is 26.6 km/h.
What are the dimensions of the Kubota L3560HSTCC?
2,920 mm × 1,521 mm.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
