Kubota B7510DTN 4WD
Series: Other models
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
The Kubota B7510DTN is a tractor from the Kubota 4WD Tractor series. Power comes from a three-cylinder engine; from 1 litres it draws 21 hp (15.7 kW). Rated output is reached at 2,600 rpm, so it works in the lower rev range.
Top speed is 13 km/h. Unladen weight is 600 kg.
Within the range, rated power spans from 18.2 to 116 hp; with 21.3 hp, the B7510DTN sits at the bottom end. Directly alongside are the BX1880 with 18.2 hp below and the BX23 with 22.3 hp above.
Technical data
Engine
| Engine model | D1005-E-D16correct |
|---|---|
| Power | 21.3 hp (15.7 kW)correct |
| Rated speed | 2,600 rpmcorrect |
| Cylinders | 3correct |
| Displacement | 1,001.2 cm³correct |
| Aspiration | E-TVCS liquid cooledcorrect |
| Coolant capacity | 4.2 lcorrect |
| Engine oil capacity | 3 lcorrect |
Dimensions and weights
| Length | 2,280 mmcorrect |
|---|---|
| Ground clearance | 299.7correct |
| Unladen weight | 600 kgcorrect |
Drivetrain and chassis
| Gearbox type | gearcorrect |
|---|---|
| Forward gears | 6correct |
| Reverse gears | 2correct |
| Tyre size | front 5-12 rear 8-16correct |
| Top speed | 13.4 km/hcorrect |
| Turning radius | 2,010 mmcorrect |
Working data
| Lifting capacity | 590 kgcorrect |
|---|---|
| Pump flow | 26.5 l/mincorrect |
| Fuel tank capacity | 20.1 lcorrect |
| PTO output | 17 hpcorrect |
More machines with this engine (D1005-E-D16, 2)
Where this model stands
Power-to-weight ratio: 26.2 kW/t (16 kW / 0.6 t)
Power class: Compact (< 40 hp)
Stronger than 9% of the tractors in the register — out of 14,914 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the Kubota B7510DTN have?
The Kubota B7510DTN delivers 21.3 hp.
How much does the Kubota B7510DTN weigh?
The unladen weight is 600 kg.
What engine does the Kubota B7510DTN have?
3 cylinders, 1,001 cm³ displacement.
How fast does the Kubota B7510DTN go?
Top speed is 13.4 km/h.
What is the PTO output of the Kubota B7510DTN?
PTO output is 17 hp.
How much does the rear linkage of the Kubota B7510DTN lift?
The rear linkage lifts 590 kg.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
