Komatsu R220LC-9A – specifications
Series: Komatsu Hydraulic Excavator
The Komatsu R220LC-9A is a model in the Komatsu Hydraulic Excavator series. The engine delivers 169.3 hp (117.1 kW), has 6 cylinders, with a displacement of 6,702.3 cm³. The engine comes from CUMMINS. Torque is 732.1 Nm. Rated speed is 1,950 rpm. The unladen weight is 22,000 kg. Ground clearance is 481.6 mm. The tank holds 400.1 litres. Maximum torque is reached at 1,500 rpm. The pump delivers 228.3 l/min. The hydraulic tank holds 275.2 litres. The cooling system holds 35.2 litres. The oil fill is 23.8 litres. The engine fitted is the QSB6,7. The Komatsu Hydraulic Excavator series covers 184 models. Rated output within it ranges from 72.1 to 3,782.5 hp; the R220LC-9A sits at the bottom of that range with 169.3 hp. Its immediate neighbours are the PC240NLC-6 below it with 168.3 hp and the PC220LC-7 above it with 170 hp. Unladen weight within it ranges from 10,300 to 685,000 kg; here the R220LC-9A sits at the bottom of that range with 22,000 kg. 1218 Komatsu models across 47 series are on record.
Build year not documented · Data origin: Directory data · sources
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Komatsu PC — what the number and dash figure actually tell you
Anyone typing “Komatsu PC120” or “PC100” is usually trying to decode the label: PC is Komatsu's crawler-excavator designation, the following number places the model roughly in a size class, and a dash number at the end marks the generation.
Read on 4 more paragraphs
Recent generations run under labels such as -8, -10 or -11; each update brings a revised engine, hydraulics and cab plus tighter emissions rules, while the base number stays the same. The added letter LC marks a widened, lengthened undercarriage that spreads more contact area on soft soil.
Alongside the PC line, Komatsu also sells models such as H135S, H455S or H655S, a separate family for very large open-pit excavators tracing back to the earlier partnership with German manufacturer Demag. Its letter-and-number logic follows its own rules and does not map onto the PC models.
The “Komatsu Hydraulic Excavator” collective entry holds both families side by side, from compact excavators starting around 53 kW up to the large H-series machines. When buying used, check the hour meter along with track rollers, chain tension and cylinder seals.
In short: the number after PC signals the size class, the dash number the generation, and models like PC100, PC120 or H655S show how wide a range sits under one register entry.
Sources: SpecCodex register, model data: Komatsu Hydraulic Excavator, Bagger-Typenschluessel im Herstellervergleich, Komatsu Seriennummern- und Generationen-Leitfaden, Demag-Komatsu H655S, Museumsarchiv
Technical data
Engine
| Engine make | CUMMINScorrect |
|---|---|
| Engine model | QSB6.7correct |
| Power | 169.3 hp (117.1 kW)correct |
| Rated speed | 1,950 rpmcorrect |
| Torque | 732.1 Nmcorrect |
| Speed at max. torque | 1,500 rpmcorrect |
| Cylinders | 6correct |
| Displacement | 6,702.3 cm³correct |
| Aspiration | turbochargedcorrect |
| Coolant capacity | 35.2 lcorrect |
| Engine oil capacity | 23.8 lcorrect |
Dimensions and weights
| Ground clearance | 481.6 mmcorrect |
|---|---|
| Unladen weight | 22,000 kgcorrect |
Working data
| Pump flow | 228.3 l/mincorrect |
|---|---|
| Hydraulic oil capacity | 275.2 lcorrect |
| Fuel tank capacity | 400.1 lcorrect |
Other data
| Cab height | 2,923 mmcorrect |
|---|
Frequently asked questions
More machines with this engine (Cummins QSB6.7, 69)
Where this model stands
Power-to-weight ratio: 5.3 kW/t (117 kW / 22 t)
Stronger than 54% of the excavators & compaction in the register — out of 1,650 models with a stated power figure.
Calculated from the documented figures above — not a rating.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
