Kerkhove ACD 303L
Built: 2000 · Series: Other models
More machines from model year 2000
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Kerkhove ACD 303L: EU class O4 trailer with a gross weight of 28,000 kg, a length of 8.85 m, a 4,550 mm wheelbase and a payload of about 22,780 kg
With a gross weight of 28,000 kg, the ACD 303L falls into EU trailer class O4. At a length of 8.85 m it is shorter than many trailers in this weight class, pointing to a compact, highly load-bearing body such as those used in heavy-haulage or building-material transport over short to medium distances.
Read on 3 more paragraphs
With an unladen weight of 5,220 kg, the trailer carries a payload of around 22,780 kg, more than four times its own weight. The body is 2.50 m wide, and the wheelbase is 4,550 mm. This ratio of low unladen weight to high payload on a comparatively short load area is typical of a design optimised for load density rather than load volume.
Class O4 trailers carry air brakes as standard and need a towing vehicle with a matching air supply and load-dependent brake force control. Driving a combination like this requires licence category CE. Trailers in this weight class also need rear underrun protection under UN/ECE Regulation R58, intended to reduce the severity of collisions where a car runs into the back of the trailer.
When buying a used trailer of this type, it is worth checking the frame for deformation caused by concentrated loads, and the brake system with its lines for leaks. The wheel bearings and suspension should be checked for play, as should whether the chassis number matches the registration papers. The rear underrun protection should additionally be checked for secure mounting and any deformation.
Sources: SpecCodex-Register: Kennwerte des Modells ACD 303L
Technical data
Dimensions and weights
| Length | 8,850 mmcorrect |
|---|---|
| Width | 2,500 mmcorrect |
| Wheelbase | 4,550 mmcorrect |
| Unladen weight | 5,220 kgcorrect |
| Gross vehicle weight | 28,000 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
How much does the Kerkhove ACD 303L weigh?
The unladen weight is 5,220 kg.
What is the gross vehicle weight of the Kerkhove ACD 303L?
28,000 kg.
Up to what speed is the Kerkhove ACD 303L approved?
Approved up to 100 km/h.
What are the dimensions of the Kerkhove ACD 303L?
8,850 mm × 2,500 mm.
When was the Kerkhove ACD 303L built?
Production years: 2000.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 8 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
Sources: RDW — Dutch national vehicle register (retrieved August 2026) · How we check the data
