Kawasaki 80ZIV-2

Series: Kawasaki Wheel Loader

Source: https://kawasaki.com.my/product/versys

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

With the 80ZIV-2, Kawasaki offers a model from the Kawasaki Wheel Loader series. The engine delivers 180.5 hp (132.7 kW), has 6 cylinders, with a displacement of 8,267.3 cm³. Torque is 755.2 Nm. Rated speed is 2,200 rpm. The unladen weight is 16,250 kg. The wheelbase measures 3,200.4 mm. Ground clearance is 460.2 mm. The tank holds 240.4 litres. The gearbox has 4 forward gears. There are also 4 reverse gears. Maximum torque is reached at 1,500 rpm. The pump delivers 65.1 l/min. The hydraulic tank holds 145.4 litres. The cooling system holds 55.3 litres. The electrical system runs on 24 V. The engine fitted is the C-8,3-C. Tyre size: 23,5x25-16PR (L-3). The Kawasaki Wheel Loader series covers 54 models. Rated output within it ranges from 131.8 to 513 hp; the 80ZIV-2 sits at the bottom of that range with 180.5 hp. Its immediate neighbours are the 80ZII below it with 167.3 hp and the 70ZV-2 above it with 195.7 hp. 58 Kawasaki models across 2 series are on record. The model is listed under Wheel loaders. 22 verified figures from 1 source are on file.

Technical data

Engine

Engine modelC-8.3-Ccorrect
Power180.5 hp (132.7 kW)correct
Rated speed2,200 rpmcorrect
Torque755.2correct
Speed at max. torque1,500 rpmcorrect
Cylinders6correct
Displacement8,267.3 cm³correct
Aspirationturbochargedcorrect
Coolant capacity55.3 lcorrect

Dimensions and weights

Wheelbase3,200.4correct
Ground clearance460.2correct
Unladen weight16,250 kgcorrect

Drivetrain and chassis

Gearbox typefull powershift transmissioncorrect
Forward gears4correct
Reverse gears4correct
Tyre size23.5x25-16PR (L-3)correct
System voltage24 Vcorrect

Working data

Pump flow65.1 l/mincorrect
Hydraulic oil capacity145.4 lcorrect
Fuel tank capacity240.4 lcorrect

Other data

Height3,377.2correct

Where this model stands

Power-to-weight ratio: 8.2 kW/t (133 kW / 16.2 t)

Stronger than 67% of the wheel loaders in the register — out of 1,253 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Kawasaki 80ZIV-2 have?

The Kawasaki 80ZIV-2 delivers 180 hp.

How much does the Kawasaki 80ZIV-2 weigh?

The unladen weight is 16,250 kg.

What engine does the Kawasaki 80ZIV-2 have?

6 cylinders, 8,267 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
