Kawasaki 50ZIV

Series: Kawasaki Wheel Loader

Source: https://www.kawasaki.eu/en/Motorcycles/EV_HEV/Ninja_7_Hybrid

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Kawasaki 50ZIV is a model in the Kawasaki Wheel Loader series. The engine delivers 67.1 kW, has 4 cylinders, with a displacement of 3,921.4 cm³. Torque is 333.5 Nm. Rated speed is 2,350 rpm. The unladen weight is 6,870 kg. The wheelbase measures 2,551.2 mm. Ground clearance is 378 mm. The tank holds 120.4 litres. The gearbox has 3 forward gears. There are also 3 reverse gears. Maximum torque is reached at 1,600 rpm. The pump delivers 102.2 l/min. The hydraulic tank holds 75.3 litres. The cooling system holds 18.2 litres. The electrical system runs on 24 V. The engine fitted is the B3,9C Diesel. Tyre size: 15,5x25-10PR (L-2). The Kawasaki Wheel Loader series covers 54 models. Rated output within it ranges from 64.9 to 536.9 kW; the 50ZIV sits at the bottom of that range with 67.1 kW. Its immediate neighbours are the 50ZIII below it with 64.9 kW and the 50ZV above it with 71.6 kW. 58 Kawasaki models across 2 series are on record. The model is listed under Wheel loaders. 21 verified figures from 1 source are on file.

Technical data

Engine

Engine modelB3.9C Dieselcorrect
Power67.1 kWcorrect
Rated speed2,350 rpmcorrect
Torque333.5correct
Speed at max. torque1,600 rpmcorrect
Cylinders4correct
Displacement3,921.4 cm³correct
Aspirationnaturalcorrect
Coolant capacity18.2 lcorrect

Dimensions and weights

Wheelbase2,551.2correct
Ground clearance378correct
Unladen weight6,870 kgcorrect

Drivetrain and chassis

Gearbox typefull powershift transmissioncorrect
Forward gears3correct
Reverse gears3correct
Tyre size15.5x25-10PR (L-2)correct
System voltage24 Vcorrect

Working data

Pump flow102.2 l/mincorrect
Hydraulic oil capacity75.3 lcorrect
Fuel tank capacity120.4 lcorrect

Other data

Height3,087.6correct

Where this model stands

Power-to-weight ratio: 9.8 kW/t (67 kW / 6.9 t)

Stronger than 33% of the wheel loaders in the register — out of 1,253 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Kawasaki 50ZIV have?

The Kawasaki 50ZIV delivers 67.1 kW.

How much does the Kawasaki 50ZIV weigh?

The unladen weight is 6,870 kg.

What engine does the Kawasaki 50ZIV have?

4 cylinders, 3,921 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 21 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
