Kawasaki 135ZV

Series: Kawasaki Wheel Loader

Source: https://www.kawasaki.eu/content/europe/master/en/Motorcycles

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The 135ZV from Kawasaki is part of the Kawasaki Wheel Loader series. The engine delivers 536.9 kW, has 12 cylinders, with a displacement of 30,496.3 cm³. Torque is 3,254 Nm. Rated speed is 2,100 rpm. The unladen weight is 79,877.6 kg. The wheelbase measures 4,800.6 mm. Ground clearance is 591.3 mm. The tank holds 1,050.1 litres. The gearbox has 4 forward gears. There are also 3 reverse gears. Maximum torque is reached at 1,300 rpm. The pump delivers 325.9 l/min. The hydraulic tank holds 720.4 litres. The cooling system holds 270.3 litres. The electrical system runs on 24 V. The engine fitted is the QST30. Tyre size: 45/65-R39 (L-5). The Kawasaki Wheel Loader series covers 54 models. Rated output within it ranges from 64.9 to 536.9 kW; the 135ZV sits at the top of that range with 536.9 kW. Its immediate neighbours are the 115ZV below it with 357.9 kW. 58 Kawasaki models across 2 series are on record. The model is listed under Wheel loaders. 21 verified figures from 1 source are on file.

Technical data

Engine

Engine modelQST30correct
Power536.9 kWcorrect
Rated speed2,100 rpmcorrect
Torque3,254correct
Speed at max. torque1,300 rpmcorrect
Cylinders12correct
Displacement30,496.3 cm³correct
Aspirationturbocharged & aftercooledcorrect
Coolant capacity270.3 lcorrect

Dimensions and weights

Wheelbase4,800.6correct
Ground clearance591.3correct
Unladen weight79,877.6 kgcorrect

Drivetrain and chassis

Gearbox typefull powershift transmissioncorrect
Forward gears4correct
Reverse gears3correct
Tyre size45/65-R39 (L-5)correct
System voltage24 Vcorrect

Working data

Pump flow325.9 l/mincorrect
Hydraulic oil capacity720.4 lcorrect
Fuel tank capacity1,050.1 lcorrect

Other data

Height4,946.9correct

Where this model stands

Power-to-weight ratio: 6.7 kW/t (537 kW / 79.9 t)

Stronger than 98% of the wheel loaders in the register — out of 1,253 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Kawasaki 135ZV have?

The Kawasaki 135ZV delivers 537 kW.

How much does the Kawasaki 135ZV weigh?

The unladen weight is 79,878 kg.

What engine does the Kawasaki 135ZV have?

12 cylinders, 30,496 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.

Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →

This page carries 21 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.

Missing a figure you were looking for? Report it →

Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
