Kawasaki 70ZV

Series: Kawasaki Wheel Loader

Source: https://www.kawasaki.eu/content/europe/master/en/Motorcycles

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The Kawasaki Wheel Loader series from Kawasaki includes the 70ZV. The engine delivers 125.3 kW, has 6 cylinders, with a displacement of 5,883 cm³. Torque is 711.8 Nm. Rated speed is 2,400 rpm. The unladen weight is 14,330 kg. The wheelbase measures 3,051 mm. Ground clearance is 405.4 mm. The tank holds 285 litres. The gearbox has 4 forward gears. There are also 4 reverse gears. Maximum torque is reached at 1,300 rpm. The pump delivers 67 l/min. The hydraulic tank holds 170.3 litres. The cooling system holds 45 litres. The electrical system runs on 24 V. The engine fitted is the QSB5,9. Tyre size: 20,5x25-12PR (L-2). The Kawasaki Wheel Loader series covers 54 models. Rated output within it ranges from 64.9 to 536.9 kW; the 70ZV sits at the bottom of that range with 125.3 kW. Its immediate neighbours are the 80ZII below it with 123 kW and the 70ZV-2 above it with 129.8 kW. 58 Kawasaki models across 2 series are on record. The model is listed under Wheel loaders. 21 verified figures from 1 source are on file.

Technical data

Engine

Engine modelQSB5.9correct
Power125.3 kWcorrect
Rated speed2,400 rpmcorrect
Torque711.8correct
Speed at max. torque1,300 rpmcorrect
Cylinders6correct
Displacement5,883 cm³correct
Aspirationturbocharged & intercoolercorrect
Coolant capacity45 lcorrect

Dimensions and weights

Wheelbase3,051correct
Ground clearance405.4correct
Unladen weight14,330 kgcorrect

Drivetrain and chassis

Gearbox typefull powershift transmissioncorrect
Forward gears4correct
Reverse gears4correct
Tyre size20.5x25-12PR (L-2)correct
System voltage24 Vcorrect

Working data

Pump flow67 l/mincorrect
Hydraulic oil capacity170.3 lcorrect
Fuel tank capacity285 lcorrect

Other data

Height3,337.6correct

Where this model stands

Power-to-weight ratio: 8.7 kW/t (125 kW / 14.3 t)

Stronger than 64% of the wheel loaders in the register — out of 1,253 models with a stated power figure.

Calculated from the documented figures above — not a rating.

Frequently asked questions

How much power does the Kawasaki 70ZV have?

The Kawasaki 70ZV delivers 125 kW.

How much does the Kawasaki 70ZV weigh?

The unladen weight is 14,330 kg.

What engine does the Kawasaki 70ZV have?

6 cylinders, 5,883 cm³ displacement.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Check the weights in the papers against the figures here — attachments change them.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
