Kakerbeck SP4/6.5E
Built: 1994 · Series: Other models
More machines from model year 1994
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Kakerbeck SP4/6.5E: EU class O3 trailer with a gross weight of 6,200 kg, a length of 6.99 m, a 3,830 mm wheelbase and a payload of about 4,040 kg
With a gross weight of 6,200 kg, the SP4/6.5E sits in EU trailer class O3, the band between 3.5 and 10 tonnes. Trailers of this size are towed by light to medium commercial vehicles and are a common middle ground between small, unbraked models and heavy semi-trailers.
Read on 3 more paragraphs
With an unladen weight of 2,160 kg, the trailer carries a payload of around 4,040 kg, nearly twice its own weight. The load area is 6.99 m long, and at 2.32 m it is narrower than the 2.55 m width permitted for road vehicles; the wheelbase is 3,830 mm.
From class O3 upward, EU rules require an air brake rather than a simple overrun brake. The comparatively narrow 2.32 m width may point to use on tighter access routes or to carrying narrower loads, for instance if the trailer was built for operations with limited manoeuvring space. Depending on the towing vehicle, licence category C1E or BE is sufficient to drive it. Trailers in this weight class also need rear underrun protection under UN/ECE Regulation R58, intended to reduce the severity of collisions where a car runs into the back of the trailer.
When buying a used trailer of this size, it is worth checking the load area for deformation and corrosion spots, and the brake lines for leaks. The wheel bearings and suspension should be checked for play, the coupling for wear, and the chassis number should match the registration papers. The rear underrun protection should additionally be checked for secure mounting and any deformation.
Sources: SpecCodex-Register: Kennwerte des Modells SP4/6.5E
Technical data
Dimensions and weights
| Length | 6,990 mmcorrect |
|---|---|
| Width | 2,320 mmcorrect |
| Wheelbase | 3,830 mmcorrect |
| Unladen weight | 2,160 kgcorrect |
| Gross vehicle weight | 6,200 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
How much does the Kakerbeck SP4/6.5E weigh?
The unladen weight is 2,160 kg.
What is the gross vehicle weight of the Kakerbeck SP4/6.5E?
6,200 kg.
Up to what speed is the Kakerbeck SP4/6.5E approved?
Approved up to 100 km/h.
What are the dimensions of the Kakerbeck SP4/6.5E?
6,990 mm × 2,320 mm.
When was the Kakerbeck SP4/6.5E built?
Production years: 1994.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 8 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
