Kaiser S 380 3C
Built: 1990 · Series: Other models
More machines from model year 1990
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
Kaiser – other models: trailers and semi-trailers outside the named ranges, from light trailers around 850 kg to heavy-haulage semi-trailers at 57 t, S type series
This page gathers the trailers and semi-trailers listed in the vehicle register under the name Kaiser that could not be assigned to a named range. Most of the model list is formed by the S type series with the designations S2102V, S3302M, S3803A, S4603J and S5703Z, whose first two digits visibly give the gross weight in tonnes; alongside these stand lighter types such as ADC11, K16 and ORIGINAL SSB15. The span thus runs from light class-O1 trailers around 850 kg to class-O4 semi-trailers with a 57-tonne gross weight.
Read on 3 more paragraphs
The register lists here 18 versions with unladen weights from 380 to 9,261 kg, gross weights from 850 to 57,000 kg, lengths from 8,200 to 13,960 mm and widths from 1,840 to 2,550 mm.
Semi-trailers with a gross weight well above 44 tonnes are built for permit-requiring heavy haulage, for example of construction machinery, steel components or transformers, while the light trailers of the S series are used in general road haulage and small trades.
When buying used, the heavy semi-trailers call for checking the axles and axle units, the brake system and air suspension, the condition of the frame girders and reinforcements, and the kingpin and fifth-wheel plate, while the light trailers call for checking the drawbar, overrun brake device and brake linkage, and rust on the frame and mudguards.
Sources: SpecCodex register, model data: Kaiser (weitere Modelle)
Technical data
Dimensions and weights
| Length | 13,600 mmcorrect |
|---|---|
| Width | 2,550 mmcorrect |
| Wheelbase | 8,850 mmcorrect |
| Unladen weight | 7,800 kgcorrect |
| Gross vehicle weight | 38,000 kgcorrect |
Drivetrain and chassis
| Top speed | 100 km/hcorrect |
|---|
Frequently asked questions
How much does the Kaiser S 380 3C weigh?
The unladen weight is 7,800 kg.
What is the gross vehicle weight of the Kaiser S 380 3C?
38,000 kg.
Up to what speed is the Kaiser S 380 3C approved?
Approved up to 100 km/h.
What are the dimensions of the Kaiser S 380 3C?
13,600 mm × 2,550 mm.
When was the Kaiser S 380 3C built?
Production years: 1990.
What to check before buying
- Search the frame and welds at the axle mounts — that is where cracks start.
- Check the brakes and the last inspection in the papers.
- Work the gross weight against the towing vehicle before buying.
- Compare the chassis number with the papers.
- Look at the floor, cover or body from the inside — rust does not show from outside.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 8 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
The technical data on this page comes from official vehicle registration records (RDW/Traficom), not from the manufacturer.
