John Deere Model BR – specifications

Built: 1936-1947 · Series: Other models

Data for the version built 1936-1947 · Data origin: Reference work (Wikipedia/Wikibooks) · sources

More machines from model year 1936

Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required

The John Deere Model BR is a historical tractor manufactured from 1936 to 1947 at the Waterloo, Iowa, USA plant. As part of John Deere's early tractor development, this model represents a specific phase in agricultural mechanization. With a total production of 6,404 units, it ranks among the common models of this era. The tractor was equipped with a proprietary John Deere engine and utilizes water cooling for thermal operation. The design is based on a two-cylinder engine with a displacement of 149 cu in, operating at a rated speed of 975 rpm.

The engine output of 14 hp at this speed defines the drawbar pull and field work capacity. A curb weight of 3,375 lbs (1,530.9 kg) ensures sufficient traction on the soil, which is crucial for transmitting drive force to the rear-wheel drive. The fuel tank capacity of 12 gal allows for longer work intervals without frequent refueling. The PTO speed of 540 rpm is the standard value for driving many agricultural implements, ensuring compatibility with common tools of the time. Operation on "all fuel" demonstrates the technical flexibility of engine designs from this epoch.

Within the lineup of early John Deere tractors, the Model BR occupies a central position. It follows the smaller predecessor models and forms the basis for subsequent generations. The specific performance data and weight position the tractor as a work machine for medium-sized farm operations. The combination of rear-wheel drive and the defined PTO speed makes it suitable for typical field tasks such as plowing and sowing. The technical design featuring water cooling and a two-cylinder engine reflects the state of the art at the time, which was focused on durability and ease of maintenance.

John Deere – other models: the collective page of tractors outside the named ranges, from the two-cylinders and the 10 series (1020, 2020) through the 40s and 50s from Mannheim to the 1023E, 3038E and 9RX, 6 to 468 kW

This page gathers the John Deere tractors the register could not assign to a named range – from the successors of the two-cylinders through the European ranges from Mannheim to the compact tractors from Augusta, Georgia. John Deere, founded in 1837 as a plough smithy in Illinois, has built tractors in Waterloo, Iowa, since 1918 and since 1956, with the takeover of Lanz, in Mannheim, today the largest tractor plant outside North America. The type logic: the 10 series of 1960 (1010 to 5010) brought the four- and six-cylinders after the two-cylinder era, the 20s, 30s and 40s (1020, 2130, 2140) the Mannheim generations of the 1960s to 1980s, in which the first digit gives the size and the last ones the generation; the 50s (1750 to 3650) followed in 1986, the 55s and 6000s in 1992. Since 1992 the first digit marks the range (1 to 9) and the following ones the power – 1023E as a 1 series compact with 23 hp, 3038E as a 3 series with 38 hp, 5075E as a 5 series with 75 hp – E, M and R the equipment lines from basic to premium. The engines are Deere's own PowerTech range in the big, Yanmar in the compact and Lombardini in the smallest tractors.

Read on 3 more paragraphs

The register lists here 925 versions with 6.3 to 468.3 kW from one- to six-cylinders of 341 to 13,503 cm³, PTO outputs from 17 to 365 hp, lift capacities from 309 to 13,494 kg, unladen weights from 363 to 20,371 kg, lengths from 2,362 to 6,880 mm and widths from 1,194 to 3,952 mm.

John Deere has been the world's largest farm-equipment maker for decades; the Mannheim 6 series is Europe's best-selling tractor, the compacts from Augusta North America's.

On used tractors, originality and engine condition count on classics, transmission (Synchron or Power-Synchron) and hydraulics on the Mannheim 40s and 50s, and on the E, M and R models operating hours, transmission (PowrQuad, AutoQuad, AutoPowr), electronics and exhaust aftertreatment; parts run through the Deere network.

Sources: SpecCodex register, model data: John Deere (weitere Modelle), John Deere (manufacturer)

Technical data

Engine

Engine makeJohn Deerecorrect
Fuelall fuelcorrect
Power14 hpcorrect
Rated speed975 rpmcorrect
Cylinders2correct
Displacement149 cu incorrect
Coolingwater-cooledcorrect

Dimensions and weights

Unladen weight3375 lbs (1530.9 kg)correct

Drivetrain and chassis

Driverear-wheel driveWDcorrect

Working data

Fuel tank capacity12 galcorrect

Origin and approval

PlantWaterloo, Iowa, USAcorrect
Units built6.404correct

Other data

PTO speed540correct

Frequently asked questions

How much power does the John Deere Model BR have?

The John Deere Model BR delivers 14 hp.

What engine does the John Deere Model BR have?

2 cylinders, all fuel.

When was the John Deere Model BR built?

Production years: 1936-1947.

What to check before buying

  • Check the hour meter against the service records — a replaced instrument is the most common gap.
  • Compare the data plate and chassis number with the papers.
  • Load the hydraulics and watch for sag.
  • Ask about parts availability for this build year — the running costs hang on it.

A general list for this type of machine — no substitute for an inspection or an appraiser.
