John Deere/goldoni 1046
Built: 1996–2003 · Series: 46er-Baureihe
More machines from model year 1996
Not the right version? The data comes from vehicle registers holding many near-identical versions side by side. Photograph the data plate — we read make and type from it. Open the scanner e-mail address required
John Deere 46 series – compact three-cylinder diesels of 1,551 to 2,940 cc, types 1046 to 1846 FA, 27 to 41 kW, kerb weight 1,175 to 2,050 kg
Listed in the register as the 46 series, the John Deere types 1046, 1546 FA and 1846 FA form a range of compact all-round tractors with three-cylinder diesel engines throughout. The models within the range cover a marked spread of displacement and power, from the smallest type 1046 to the strongest 1846 FA, indicating a staggered line-up within a shared range aimed at smallholders and part-time farms.
Read on 3 more paragraphs
The register lists 3 versions here with 27.2 to 41.2 kW from three-cylinder diesel engines of 1,551 to 2,940 cc at 2,300 to 3,000 rpm, kerb weights of 1,175 to 2,050 kg, lengths of 2,750 to 3,267 mm, widths of 1,180 to 1,460 mm and heights of 1,910 to 2,110 mm; one of the versions is additionally recorded with a torque of 86.3 Nm.
With its compact three-cylinder layout and wide power spread, the 46 series targeted smaller and medium holdings looking for a manoeuvrable all-rounder for field, yard and transport work, without reaching into the class of large agricultural tractors used in professional arable farming.
When buying a used model from this range, the key points are the condition of the engine and injection pump, wear on clutch and gearbox, and tightness of the hydraulics, plus corrosion on cab and chassis and the condition of the front loader mounts where fitted; spare parts for the engine and many attachments are available through John Deere parts channels.
Sources: SpecCodex register, model data: John Deere 46er-Baureihe, John Deere (manufacturer)
Technical data
Engine
| Fuel | dieselcorrect |
|---|---|
| Power | 37 hp (27.2 kW)correct |
| Rated speed | 3,000 rpmcorrect |
| Torque | 86.3 Nmcorrect |
| Cylinders | 3correct |
| Displacement | 1,551 cm³correct |
| Bore | 88 mmcorrect |
| Stroke | 85 mmcorrect |
| Compression ratio | 22correct |
| Cooling | water-cooledcorrect |
Dimensions and weights
| Length | 2,750 mmcorrect |
|---|---|
| Width | 1,180 mmcorrect |
| Height | 1,910 mmcorrect |
| Wheelbase | 1,600 mmcorrect |
| Ground clearance | 285 mmcorrect |
| Unladen weight | 1,175 kgcorrect |
Drivetrain and chassis
| Drive | four-wheel drivecorrect |
|---|---|
| Gearbox | 12V/4Rcorrect |
| Front tyres | 5.00-15correct |
| Rear tyres | 11.2 R 20correct |
| Top speed | 30 km/hcorrect |
Where this model stands
Power-to-weight ratio: 23.1 kW/t (27 kW / 1.2 t)
Power class: Compact (< 40 hp)
Stronger than 23% of the tractors in the register — out of 15,663 models with a stated power figure.
Calculated from the documented figures above — not a rating.
Frequently asked questions
How much power does the John Deere/goldoni 1046 have?
The John Deere/goldoni 1046 delivers 37 hp.
How much does the John Deere/goldoni 1046 weigh?
The unladen weight is 1,175 kg.
What engine does the John Deere/goldoni 1046 have?
3 cylinders, 1,551 cm³ displacement, Diesel.
How fast does the John Deere/goldoni 1046 go?
Top speed is 30 km/h.
What are the dimensions of the John Deere/goldoni 1046?
2,750 mm × 1,180 mm × 1,910 mm.
When was the John Deere/goldoni 1046 built?
Production years: 1996–2003.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Check the weights in the papers against the figures here — attachments change them.
- Check front and rear tyre sizes: mismatched pairs strain the drivetrain.
- Shift the gearbox cold and warm — jumps only show up at temperature.
- Load the hydraulics and watch for sag.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 22 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
