John Deere 90
Series: John Deere Skid Steer Loader
The John Deere 90 is a model in the John Deere Skid Steer Loader series. The engine delivers 17.2 kW, has 2 cylinders, with a displacement of 983.2 cm³. Rated speed is 3,000 rpm. The wheelbase measures 783.3 mm. Ground clearance is 171.4 mm. Top speed is 8 km/h. The tank holds 27.3 litres. The pump delivers 28.4 l/min. The hydraulic tank holds 41.6 litres. Working pressure is 120.7 bar. The electrical system runs on 12 V. Tyre size: 8,50-15. The John Deere Skid Steer Loader series covers 29 models. Rated output within it ranges from 12.7 to 63.4 kW; the 90 sits at the bottom of that range with 17.2 kW. Its immediate neighbours are the 60 below it with 12.7 kW and the JD14 above it with 18.6 kW. 2153 John Deere models across 96 series are on record. The model is listed under Wheel loaders. 14 verified figures from 1 source are on file.
Technical data
Engine
| Power | 17.2 kWcorrect |
|---|---|
| Rated speed | 3,000 rpmcorrect |
| Cylinders | 2correct |
| Displacement | 983.2 cm³correct |
Dimensions and weights
| Wheelbase | 783.3correct |
|---|---|
| Ground clearance | 171.4correct |
Drivetrain and chassis
| Tyre size | 8.50-15correct |
|---|---|
| Top speed | 8 km/hcorrect |
| System voltage | 12 Vcorrect |
Working data
| Pump flow | 28.4 l/mincorrect |
|---|---|
| Hydraulic oil capacity | 41.6 lcorrect |
| Hydraulic pressure | 120.7correct |
| Fuel tank capacity | 27.3 lcorrect |
Other data
| Height | 1,880.6correct |
|---|
Frequently asked questions
How much power does the John Deere 90 have?
The John Deere 90 delivers 17.2 kW.
What engine does the John Deere 90 have?
2 cylinders, 983 cm³ displacement.
How fast does the John Deere 90 go?
Top speed is 8 km/h.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
