John Deere 260
Series: John Deere Skid Steer Loader
The 260 from John Deere is part of the John Deere Skid Steer Loader series. The engine delivers 73.4 hp (51.5 kW), has 3 cylinders, with a displacement of 2,933.3 cm³. Rated speed is 2,400 rpm. The wheelbase measures 1,210.1 mm. Ground clearance is 279.4 mm. Top speed is 19.3 km/h. The tank holds 75.7 litres. The pump delivers 125.3 l/min. The hydraulic tank holds 34.1 litres. Working pressure is 213.7 bar. The cooling system holds 11 litres. The electrical system runs on 12 V. The engine fitted is the 3029T. Tyre size: 14x17,5 SKS, 12PR. The John Deere Skid Steer Loader series covers 29 models. Rated output within it ranges from 19.3 to 92.3 hp; the 260 sits in the upper part of that range with 73.4 hp. Its immediate neighbours are the 320 below it with 66.9 hp and the 325 above it with 77.1 hp. 2153 John Deere models across 96 series are on record. The model is listed under Wheel loaders. 17 verified figures from 1 source are on file.
Technical data
Engine
| Engine model | 3029Tcorrect |
|---|---|
| Power | 73.4 hp (51.5 kW)correct |
| Rated speed | 2,400 rpmcorrect |
| Cylinders | 3correct |
| Displacement | 2,933.3 cm³correct |
| Coolant capacity | 11 lcorrect |
Dimensions and weights
| Wheelbase | 1,210.1correct |
|---|---|
| Ground clearance | 279.4correct |
Drivetrain and chassis
| Tyre size | 14x17.5 SKS. 12PRcorrect |
|---|---|
| Top speed | 19.3 km/hcorrect |
| System voltage | 12 Vcorrect |
Working data
| Pump flow | 125.3 l/mincorrect |
|---|---|
| Hydraulic oil capacity | 34.1 lcorrect |
| Hydraulic pressure | 213.7correct |
| Fuel tank capacity | 75.7 lcorrect |
Other data
| Height | 2,106.2correct |
|---|
Frequently asked questions
How much power does the John Deere 260 have?
The John Deere 260 delivers 73.4 hp.
What engine does the John Deere 260 have?
3 cylinders, 2,933 cm³ displacement.
How fast does the John Deere 260 go?
Top speed is 19.3 km/h.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
Looking for this machine?
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
We do not sell machines. We ask the dealers who carry this model and come back with price and lead time.
Request a quote →
Need parts for this model?
We ask the suppliers and come back with price and lead time.
Request spare parts →
We ask the suppliers and come back with price and lead time.
Request spare parts →
This page carries 17 individual figures for this model. They come from 1 recorded source; every figure can be traced there. What we cannot document is not here — we leave gaps open rather than estimate them.
Missing a figure you were looking for? Report it →
Know this machine better? Have a photo, a manual, or know that a figure is wrong? Add it to the register →
