John Deere 325
Series: John Deere Skid Steer Loader
The John Deere 325 is a model in the John Deere Skid Steer Loader series. The engine delivers 77.1 hp (52.2 kW), has 5 cylinders, with a displacement of 3,048 cm³. Rated speed is 2,800 rpm. The wheelbase measures 1,210.1 mm. Ground clearance is 228.6 mm. Top speed is 17.7 km/h. The tank holds 91.2 litres. The pump delivers 83.3 l/min. Working pressure is 213.7 bar. The electrical system runs on 12 V. The engine fitted is the 5030T. Tyre size: 12x16,5 8 PR SKS. The John Deere Skid Steer Loader series covers 29 models. Rated output within it ranges from 19.3 to 92.3 hp; the 325 sits in the upper part of that range with 77.1 hp. Its immediate neighbours are the 260 below it with 73.4 hp and the 270 Series II above it with 82.1 hp. 2153 John Deere models across 96 series are on record. The model is listed under Wheel loaders. 16 verified figures from 1 source are on file.
Technical data
Engine
| Engine model | 5030Tcorrect |
|---|---|
| Power | 77.1 hp (52.2 kW)correct |
| Rated speed | 2,800 rpmcorrect |
| Cylinders | 5correct |
| Displacement | 3,048 cm³correct |
| Aspiration | turbochargedcorrect |
Dimensions and weights
| Wheelbase | 1,210.1correct |
|---|---|
| Ground clearance | 228.6correct |
Drivetrain and chassis
| Tyre size | 12x16.5 8 PR SKScorrect |
|---|---|
| Top speed | 17.7 km/hcorrect |
| System voltage | 12 Vcorrect |
Working data
| Pump flow | 83.3 l/mincorrect |
|---|---|
| Hydraulic pressure | 213.7correct |
| Fuel tank capacity | 91.2 lcorrect |
Other data
| Height | 2,057.4correct |
|---|
Frequently asked questions
How much power does the John Deere 325 have?
The John Deere 325 delivers 77.1 hp.
What engine does the John Deere 325 have?
5 cylinders, 3,048 cm³ displacement.
How fast does the John Deere 325 go?
Top speed is 17.7 km/h.
What to check before buying
- Check the hour meter against the service records — a replaced instrument is the most common gap.
- Compare the data plate and chassis number with the papers.
- Ask about parts availability for this build year — the running costs hang on it.
A general list for this type of machine — no substitute for an inspection or an appraiser.
